The Illinois Engineered Products HYDS975 Storefront Security Gate is a full-width, single-gate system designed to secure storefronts, warehouse areas, or other sensitive spaces. With a width of 9 feet and a height of 7.5 feet, this gate provides continuous coverage using a combination of vertical bars that ride in tracks and a traditional scissor lattice. The design enables rapid setup and straightforward installation, while the built-in folding top and bottom track options support flexible positioning in tighter spaces or when expanding and retracting the gate is needed.
Constructed from galvanized steel, the HYDS975 features a frame of 1-1/4 inch by 5/8 inch 14-gauge C-channel steel and a lattice of 3/8 inch by 3/4 inch 14-gauge U-channel steel, reinforced with zinc-plated rivets. It ships unassembled and carries a 1-year manufacturer warranty. A padlock hasp comes standard, and an integrated cylinder lock is available as an option, offering configurable security to suit site requirements. Finish options include galvanized steel with powder coat colors available on request, enabling some alignment with site aesthetics or corrosion resistance needs in varied environments.
The gate is designed to withstand indoor and outdoor conditions, including exposure to heat, rain, snow, and harsh industrial cleaners or chemicals. This makes it suitable for high-traffic storefronts, loading bays, or perimeter bands within industrial facilities where wide, secure access points are needed. The HYDS975 is offered as a single gate in a non-returnable configuration, with top and bottom track styles available and other sizes in the product family for broader security planning. When selected, ensure the chosen locking option and finish align with your security policy and environmental exposure to maximize longevity and performance.
Features:
- Combination of vertical bars and scissor gates for total coverage
- Indoor or outdoor use; withstands heat, rain, snow, and harsh chemicals
- Top & bottom track styles available in multiple sizes
- Galvanized steel with optional powder coat finish
- Padlock hasp standard; integrated cylinder lock optional
- Ships unassembled for flexible installation
- Width:
- 9'
- Height:
- 7.5'
- Max Width:
- 9'
- Folded Lattice Height:
- 7.5'
- Top Frame Style:
- Folding
- Expanded Lattice Height:
- 7'
- Frame:
- 1-1/4 x 5/8 14 gauge C-channel steel with rubber grommet feet
- Lattice:
- 3/8 x 3/4 14 gauge U-channel steel with 1/4 x 1-1/2 zinc plated steel rivets
- Locking Options:
- Padlock hasp comes standard, integrated cylinder lock is optional
- Finish:
- Galvanized steel, powder coat colors available on request
- Top Bottom Track:
- 1-7/8 x 1-3/8 11 gauge box channel steel
- Warranty:
- 1-year manufacturer warranty
- Assembly:
- Ships unassembled
- Type:
- Storefront Security Gate - Single Gate
- Weight:
- 169.0 lbs. ea.
- Package Size:
- Each
