The Illinois Engineered Products HYDS775 storefront security gate is a full-width, single-gate barrier designed to secure storefronts, warehouses, and work areas. It combines vertical bars that ride in tracks with a traditional scissor lattice, providing continuous coverage across a 7-foot-wide opening and a 7.5-foot-tall height. The gate ships unassembled and is intended for quick setup and smooth expansion or retraction, making it suitable for spaces where temporary yet reliable access control is needed. The design leverages galvanized steel construction with 14-gauge framing and lattice, and features a folding top frame style along with top and bottom tracks to support operation in various layouts.
Features:
- Combination of vertical bars and scissor gates for total coverage and security
- Versatile indoor/outdoor use with resistance to heat, rain, snow, and harsh chemicals
- Top and bottom track styles available; other sizes offered on request
- 1-year manufacturer warranty
- Padlock hasp standard; integrated cylinder lock option available
- Galvanized steel construction with robust 14 gauge and C-channel framing
- Ships unassembled for easier handling and installation
- Width:
- 7'
- Height:
- 7.5'
- Max Width:
- 7'
- Folded Lattice Height:
- 7.5'
- Top Frame Style:
- Folding
- Expanded Lattice Height:
- 7'
- Frame:
- 1-1/4 x 5/8 14 gauge C-channel steel with rubber grommet feet
- Lattice:
- 3/8 x 3/4 14 gauge U-channel steel with 1/4 x 1-1/2 zinc plated steel rivets
- Locking Options:
- Padlock hasp comes standard, integrated cylinder lock is optional
- Finish:
- Galvanized steel, powder coat colors available on request
- Top Bottom Track:
- 1-7/8 x 1-3/8 11 gauge box channel steel
- Warranty:
- 1-year manufacturer warranty
- Assembly:
- Ships unassembled
- Type:
- Storefront Security Gate - Single Gate
- Weight:
- 131.0 lbs. ea.
- Package Size:
- Each
