The Illinois Engineered Products HYDS875 storefront security gate is a full-width, single-gate system designed to secure storefronts, warehouse entries, or interior zones. With an 8' wide by 7.5' high footprint, this unit uses a combination of vertical bars riding in tracks and a folding lattice for continuous coverage and easy expansion or retraction. The folding top and bottom track configuration provides structural support while maintaining smooth operation, and the assembly ships unassembled for on-site fit and installation. The gate is constructed from galvanized steel with a 14-gauge frame and 14-gauge lattice components, reinforced by 1-1/4" x 5/8" C-channel steel frame and 3/8" x 3/4" 14-gauge lattice, all backed by zinc-plated rivets and rubber-grommet feet for stability. A padlock hasp is included as a standard locking option, with an integrated cylinder lock offered as an additional choice to suit security requirements. The unit is designed to withstand indoor, outdoor, and harsh industrial conditions, including exposure to heat, rain, snow, and chemical cleaners. Finishing options include galvanized steel with powder coat color options available on request to suit site aesthetics or branding.
This storefront gate prioritizes practical loss prevention through a secure, scalable design. It can be used to section off areas within a facility or shield storefront locations from tampering while remaining operable for quick access when needed. The HYDS875 ships as a single gate per package and weighs approximately 150 lbs, with mounting and installation considerations dependent on site configuration and track mounting needs. While not described as returnable, it’s intended for long-term use in challenging environments, with a 1-year manufacturer warranty backing the product.
Choosing this gate supports rapid deployment where space is a premium and continuous coverage is required. The combination of vertical bars and scissor lattice delivers a robust barrier while the integrated track system ensures dependable movement for frequent access and retraction. Proper installation and track alignment are essential to achieve consistent operation and security performance.
Features:
- Combination of vertical bars and scissor gates for total coverage and enhanced security
- All-weather design for indoor and outdoor use, resistant to heat, rain, snow, and harsh cleaners
- Top & bottom track styles available with other size options
- Galvanized steel construction with durable channel framing
- Padlock hasp standard; Integrated cylinder lock optional
- Ships unassembled for flexible installation
- Width:
- 8'
- Height:
- 7.5'
- Max Width:
- 8'
- Folded Lattice Height:
- 7.5'
- Top Frame Style:
- Folding
- Expanded Lattice Height:
- 7'
- Frame:
- 1-1/4 x 5/8 14 gauge C-channel steel with rubber grommet feet
- Lattice:
- 3/8 x 3/4 14 gauge U-channel steel with 1/4 x 1-1/2 zinc plated steel rivets
- Locking Options:
- Padlock hasp comes standard, integrated cylinder lock is optional
- Finish:
- Galvanized steel, powder coat colors available on request
- Top Bottom Track:
- 1-7/8 x 1-3/8 11 gauge box channel steel
- Warranty:
- 1-year manufacturer warranty
- Assembly:
- Ships unassembled
- Type:
- Storefront Security Gate - Single Gate
- Weight:
- 150.0 lbs. ea.
- Package Size:
- Each
