Vestil VESHBD-4-60 Electric/Hydr Box Dumper is a controlled material-dumping solution designed to empty contents from boxes, crates, and similar containers. Its primary function is to facilitate safe, elevated dumping for palletized loading and unloading operations, with an integrated power unit that rotates the chute at the push of a button. The unit supports precise operation, offering a maximum dump angle of 135 degrees and an adjustable hold-down range to accommodate containers of varying heights, helping to stabilize loads during dumping. A complete electric/hydraulic power system powers the rotation and dumping cycle, while protective mesh side screens enhance operator safety during operation and maintenance tasks.
Constructed from heavy-duty welded steel, the dumper provides a durable platform for frequent industrial use. The design includes a wide usable chute area and a defined reach at full rotation, along with a compact lowered height that aids in installation and access in constrained spaces. The 24-volt handheld control and 8-foot control cable enable remote operation from a safe distance, supporting safer handling practices in busy material-handling environments. The unit’s color scheme combines blue and yellow, which helps with visibility in active warehouses and factories.
This model is suitable for applications requiring dumping from a variety of container sizes and shapes, particularly where electric/hydraulic actuation can streamline unloading workflows. Consider its 60-inch dump height and 52 by 50 inch chute footprint when evaluating fit over pallets or containers, and account for the unit’s 4,000 lb maximum usable capacity and 15 starts-per-hour duty profile. Ensure compatibility with your existing power distribution (460V/3-phase) and the included hand-held controller for reliable, on-demand operation. The package is listed as single-unit packaging and includes safety screens for side protection during operation and maintenance tasks.
Features:
- Universal design dumps contents of many container types and sizes
- 135° maximum dump angle with adjustable stopping point
- Complete electric/hydraulic power unit to rotate chute via handheld control
- Safety mesh screens on both sides for added operator protection
- 4,000 lb maximum capacity and 60" dump height
- Handheld control, 24V, with 8 ft control cord; 460V/3-phase input
- Color:
- Blue / Yellow
- Material:
- Steel
- Uniform Capacity (lb.):
- 4000
- Dump Height (in.):
- 60
- Rotated Height (in.):
- 149-1/2
- Lowered Height (in.):
- 3/8
- Usable Chute Width/Length (in.):
- 52 x 50
- Chute Reach at Full Rotation (in.):
- 10
- Hold Downs (in.):
- 18 to 50
- Maximum Rotation Travel (degree):
- 135
- Dump Angle (degree):
- 45
- Motor Horsepower:
- 2
- Voltage:
- 460/3 Phase
- Maximum Duty Cycle Starts Per Hour:
- 15
- Hand Held Control (volts):
- 24
- Hand Held Control Length (ft.):
- 8
- Standard Output:
- AC
- Cord Length (ft.):
- 2
- Package Size:
- Each
