ILP ILPOLE-SS-4-20-11-DX 20 Foot Square Steel Light Pole 4 Inch Wide 11 Gauge Dark Bronze Quick Ship

Customer Reviews
SKU:
ILPOLE-SS-4-20-11-DX
Weight:
50.00 LBS



$853.63
/ Each

Description

This square steel light pole has a 20 foot height and 4 inch width with a wall thickness gauge of 11 and maximum EPA rating of 3.1 at 120 mph. To see the full specifications for this pole refer to its specification sheet: 20 foot square steel 4 inch width 11 gauge light pole. All materials used in manufacturing this square steel pole are commercial quality, weldable grade, hot rolled carbon steel tubing and all welds confirm to AWS D1.1 using E70xx electrodes.

This light pole includes galvanized steel anchor bolts for a bolt circle diameter of 8-9 inches, a 2 piece metal base cover, and reinforced handhole with steel cover and stainless steel screws. Materials for the base plate and handhole cover conform to ASTM A36 standards. This light pole is only available in dark bronze.

Save with The Safety Source

At The Safety Source, we keep our prices low without compromising the quality our customers expect from us. Place your order through our secure website with confidence. If you would like assistance with your order, please call us at 1-866-688-7233 or message us online now. Get the best deal with The Safety Source.

Product Features:

  • Shaft – 55,000 p.s.i minimum yield
  • Base Covers
  • Base Plates – 36,000 p.s.i. minimum yield
  • Reinforced handholes with grounding lug and removable cover
  • Top tenon or drill pattern with removable pole cap
  • Four galvanized anchor bolts w/ galvanized hardware
  • Anchor bolt templates included
  • Optional Pole Colors: Black (BLK), Silver (SLV), & White (WHT) & custom colors upon request.
  • Pole Vibration Dampeners available upon request
  • Limited Lifetime Warranty

Applications:

  • Parking Lots
  • Buildings
  • General Area Lighting

Downloads:

Product Specifications:

Package Size Each
Package Includes 1/Each
Housing Material Steel
Color Finish Bronze
Warranty Limited Lifetime
SKU:
ILPOLE-SS-4-20-11-DX
Weight:
50.00 LBS
Package Size:
Each
Package Includes:
1/Each
Housing Material:
Steel
Color Finish:
Bronze
Warranty:
Limited Lifetime
