Vestil WL-100-12-68 Steel Premium Truck Scissor Dock Lift is designed to facilitate safe, efficient loading and unloading from semi-trailers when a fixed loading dock isn’t available. Built with a heavy-gauge steel deck featuring diamond plate for a non-slip surface, this lift provides a stable platform that can raise trailer heights to match dock levels. The system includes a safety-velocity fuse on the hydraulic cylinders, an upper travel limit switch that de-energizes the unit at the maximum height, and a pre-wired control setup with a 20-foot coil cord and magnetic starter/overload relay in the control box. High visibility, removable safety rails and full toe guards ensure perimeter protection during operation.
This model is engineered to handle demanding material-handling tasks with a rated capacity of 12,000 lb and an overall frame width of 62 inches. The external drive components are configured so the 6.5 HP, 460V, 3-phase motor can be located up to 8 feet away from the lift, providing flexibility in equipment layout. The combination of rugged construction and integrated safety features supports frequent use in busy dock environments where portable elevation is needed to bridge the gap between dock and trailer bed.
When planning use, consider the lift’s palletized loading workflow, trailer height variations, and the available space for platform travel. The package is specified as a single unit, with the platform width and capacity central to determining compatibility with your trailers and handling loads. Regular inspection of the hydraulic system and safety devices is important to maintain reliable operation. Maintain awareness of the 62-inch overall frame width when positioning the unit to avoid interference with nearby equipment or structures.
Features:
- Unique design services semi-trailers when loading dock is unavailable
- Tread plate surface provides a safe non-slip grip
- Safety velocity fuses protect the hydraulic cylinders
- Upper travel limit switch cuts power to unit when max raised height is reached
- 12,000 lb uniform capacity for demanding material handling tasks
- Uniform Capacity (lb.):
- 12000
- Overall Frame Width (in.):
- 62
- Package Size:
- Each
