ETI HB-16200LM-8-50K-MV-LVD 63802161 – 120W ECO Round High Bay, 10.2″ Dia., 120-277V, 0-10V Dimming, DLC Premium

Customer Reviews
SKU:
HB-16200LM-8-50K-MV-LVD
Weight:
9.48 LBS



Out of stock

$159.49
/ Each

Description

ETi SSL’s HB ECO Round High Bay Series combines a robust and durable die-cast design with excellent performance (17,651 - 29,756 lumen packages available @ up to 148 LPW) It is an ideal design solution with its universal round form factor for many new construction and retrofit commercial and industrial applications. Our products are engineered using the latest innovative LED technologies to provide the perfect mix of modern design, performance, world class quality and reliability. All at a superior value to the designer, specifier, contractor and end-user. The HB series is rated IP65 to minimize environmental impact from contaminants like dust and bugs to maximize photometric performance over the lifetime of the luminaire. Our extremely efficient optical system qualifies for DLC Premium for superior energy savings and can qualify for maximum energy rebate opportunities. The HB series delivers a performance first uniform light distribution optimized for most general open space applications. Optional secondary drop prismatic and aluminum reflectors are available for additional design flexibility. Each fixture includes an optional diffusing lens filter that can be easily installed to help significantly reduce direct-view visual glare, brightness and LED pixelation for superior visual comfort within the space when needed. Robust thermal management is optimized thanks to the luminaire’s pass-through convective cooling die-cast heatsink design. Helping to maximize the total system life and performance of the luminaire. Even in demanding high ambient applications thanks to our 50o C high ambient temperature rating. ETi takes great pride in our dedication to providing solutions with the product reliability and quality that you can always depend on.



Save with The Safety Source

At The Safety Source, we keep our prices low without compromising the quality our customers expect from us. Place your order through our secure website with confidence. If you would like assistance with your order, please call us at 1-866-688-7233 or message us online now. Get the best deal with The Safety Source.

Product Features:

  • All configurations to be DLC Premium qualified for max energy savings & rebates
  • Up to 148 LPW provides 60+% in energy savings vs. legacy HID, T5 & T8 luminaires
  • 120W @ 17,651 lumens, 150W @ 22,242 lumens, 202W @ 29,756 lumens
  • 80+ CRI standard for true accurate color rendering & visual performance
  • Fixture ships w/ optional diffusing lens filter to improve visual glare (field installed)
  • Die-cast design w/ pass-through convective heatsink maximizes life & performance
  • -40o to 50o C (-40o to 122o F) high ambient temp rating for demanding applications
  • IP65 rated luminaire minimizes environmental impact from contaminants
  • Robust 4kV LED driver surge protection is standard for added protection 5 WARRANTY YEAR
  • Reported L75/102,000, Projected L70 @ 128,000 hours (per IES TM21)
  • Drop prismatic or aluminum reflectors available for added design flexibility
  • Standard universal O-ring mount for quick & easy pendant installation
  • Weighing in at only 9.3 lbs allows for ease of handling & fixture installation
  • Optional yoke mount w/ hook allows for tilt aiming & added install flexibility
  • 120-277V drivers w/ 0-10V dimming (down to 10%) capability as standard
  • Optional occupancy sensor for added energy savings & code compliance
  • BBU options for safety & code compliance (CA Title 20 MAEDBS, COMING SOON)
  • Ideal for many commercial & industrial applications (retrofit & new construction)

Applications:

  • Indoor Warehouse
  • Gymnasium
  • Recreational Space
  • Retail
  • Public Spaces
  • Schools
  • Loading Dock
  • Garages Assembly Lines/Production Facilities.

Product Specifications:

Package Size Each
Package Includes 1/Each
Wattage 120
Lumens 17651 Lumens
Lumens Per Watt 147
Fluorescent Equal T8 4 lamp, T8 6 lamp
HID Equal 400 Watt
Input Voltage 120-277V
Color Temp 5000K
CRI >80
Dimmable No
UL Listed Yes
ETL Listed No
DLC Listed Yes
DLC Premium Listed Yes
Wet Location No
Damp Location Yes
Hazardous Location No
Certifications RoHS
Color Finish White
Lens Type Glass
Mounting Type Suspended - Hook
Shape Round
Motion Sensor Included No
Emergency Battery Included No
Operating Temperature Range -40°F to 113°F
Life Rating L70 50,000 Hours
Warranty 5 Years
SKU:
HB-16200LM-8-50K-MV-LVD
Weight:
9.48 LBS
Package Size:
Each
Package Includes:
1/Each
Wattage:
120
Lumens:
17651 Lumens
Lumens Per Watt:
147
Input Voltage:
120-277V
Color Temp:
5000K
CRI:
>80
Dimmable:
No
UL Listed:
Yes
ETL Listed:
No
DLC Listed:
Yes
DLC Premium Listed:
Yes
Wet Location:
No
Damp Location:
Yes
Hazardous Location:
No
Certifications:
RoHS
Color Finish:
White
Lens Type:
Glass
Mounting Type:
Suspended - Hook
Shape:
Round
Motion Sensor Included:
No
Emergency Battery Included:
No
Operating Temperature Range:
-40°F to 113°F
Life Rating L70:
50,000 Hours
Warranty:
5 Years
