The Illinois Engineered Products HYB-SFSP-CL-4071 is a full-width storefront-style security gate designed to create secure, movable barriers across open spaces such as warehouse aisles or storefront perimeters. This single-gate system spans a width of 40 inches and rises to 7 feet 1 inch, providing a continuous barrier that can be expanded or retracted as needed. The design combines vertical bars that ride in tracks with a traditional scissor lattice, delivering a convincing balance of coverage and security while maintaining smooth operation. The gate is constructed from galvanized steel components, with 1-1/4 inch by 5/8 inch 14 gauge C-channel frame and 3/8 inch by 3/4 inch 14 gauge U-channel lattice, reinforced by zinc-plated rivets and rubber grommet feet to help mitigate ground contact noise and wear. A padlock hasp is included as a standard locking option, while an integrated cylinder lock is available as an add-on for higher security requirements. The product ships unassembled and includes a top and bottom track configuration, with options for powder coat finishes on request to suit site aesthetics or corrosion considerations. The HYB-SFSP-CL-4071 is suitable for indoor or outdoor use and is designed to resist typical industrial exposure, including heat, rain, snow, and common chemicals or cleaners encountered in facility environments. Its 140-pound weight reflects a sturdy, semi-permanent installation that can be positioned to sections or folders of traffic as needed, supporting loss prevention without hindering access when retracted. This model is offered as a storefront security gate—Single Gate—with a one-year manufacturer warranty, and it is non-returnable per the manufacturer’s terms.
Why these verified construction details matter: the combination of 1-1/4 x 5/8 C-channel framing and 3/8 x 3/4 U-channel lattice provides specific load paths and bar spacing that influence both security performance and ease of operation. The dual-track top and bottom guidance reduces racking and helps maintain alignment over time, which is critical for consistent expansion, retraction, and long-term service in busy facilities.
Features:
- Hybrid design combines vertical bars and scissor gates for full coverage
- Indoor or outdoor use with resistance to heat, rain, snow, and harsh cleaners
- Fixed top track with folding bottom option for secure, adaptable access control
- Galvanized steel construction with robust framing and U-channel lattice
- Padlock hasp standard; integrated cylinder lock option available
- Ships unassembled for flexible installation in various setups
- 1-year manufacturer warranty
- Width:
- 40
- Height:
- 7'1
- Max Width:
- 40
- Top Frame Style:
- Fixed
- Frame:
- 1-1/4 x 5/8 14 gauge C-channel steel with rubber grommet feet
- Lattice:
- 3/8 x 3/4 14 gauge U-channel steel with 1/4 x 1-1/2 zinc plated steel rivets
- Locking Options:
- Padlock hasp comes standard, integrated cylinder lock is optional
- Finish:
- Galvanized steel, powder coat colors available on request
- Top Bottom Track:
- 1-7/8 x 1-3/8 11 gauge box channel steel
- Warranty:
- 1-year manufacturer warranty
- Assembly:
- Ships unassembled
- Type:
- Storefront Security Gate - Single Gate
- Weight:
- 140 lbs
- Package Size:
- Each
