The Illinois Engineered Products HYDS712 Storefront Security Gate provides a full-width, secure barrier designed to segment storefronts, warehouse areas, or entry points. This single-gate system combines vertical bars that ride in tracks with a traditional scissor lattice to deliver continuous coverage and enhanced loss prevention. With a width of 7 feet and a height of 12 feet, the gate ships unassembled and features a galvanized steel frame and lattice components that are designed to withstand varied conditions, making it suitable for indoor or outdoor use in demanding environments. The design includes top and bottom tracks for smooth operation and secure mounting, and it offers both a standard padlock hasp and an optional integrated cylinder lock to control access as needed.
Construction details emphasize rigidity and durability: the frame uses 1-1/4 inch by 5/8 inch, 14 gauge C-channel steel, while the lattice employs 3/8 inch by 3/4 inch, 14 gauge U-channel steel with reinforced rivets. The assembly accommodates a variety of mounting configurations, and finished options include galvanized steel with powder coat colors available on request to suit site aesthetics and corrosion resistance needs. A 1-year manufacturer warranty provides a baseline level of assurance against defects in materials and workmanship. Weight is substantial at about 210 pounds per unit, reflecting the sturdy, industrial-grade construction intended for high-traffic security applications.
This storefront gate is designed for rapid setup and dependable performance in spaces where security, access control, and obstruction reduction are priorities. It supports use cases such as partitioning large spaces, securing storefronts during off-hours, or creating controlled zones within warehouses. When planning installation, consider the available top and bottom track styles, potential environmental exposure, and the need for a locking option to match site security requirements. The HYDS712 is manufactured for settings that demand durable metal construction and reliable operation across diverse conditions.
Features:
- Combination of vertical bars and scissor gates for full coverage and security
- Indoor or outdoor deployment, resistant to heat, rain, snow, and harsh cleaners
- Top fixed frame with folding bottom gate for versatile access
- Galvanized steel construction with optional powder coat finish
- Ships unassembled; includes standard padlock hasp (cylinder lock optional)
- Maximum width 7', height 12'; 210 lbs per unit
- Width:
- 7'
- Height:
- 12'
- Max Width:
- 7'
- Folded Lattice Height:
- 12'
- Top Frame Style:
- Fixed
- Expanded Lattice Height:
- 11.5'
- Frame:
- 1-1/4 x 5/8 14 gauge C-channel steel with rubber grommet feet
- Lattice:
- 3/8 x 3/4 14 gauge U-channel steel with 1/4 x 1-1/2 zinc plated steel rivets
- Locking Options:
- Padlock hasp comes standard, integrated cylinder lock is optional
- Finish:
- Galvanized steel, powder coat colors available on request
- Top Bottom Track:
- 1-7/8 x 1-3/8 11 gauge box channel steel
- Warranty:
- 1-year manufacturer warranty
- Assembly:
- Ships unassembled
- Type:
- Storefront Security Gate - Single Gate
- Weight:
- 210.0 lbs. ea.
- Package Size:
- Each
