The Illinois Engineered Products HYDS612 storefront security gate is a full-width, concrete-installed barrier designed to secure storefronts, warehouse entrances, and restricted areas. This single-gate system spans 6 feet in width and stands 12 feet high, offering continuous coverage with a combination of vertical bars riding in tracks and a traditional scissor lattice for enhanced loss prevention. The unit ships unassembled and includes a 1-year manufacturer warranty. The frame is constructed from 1-1/4 inch by 5/8 inch 14-gauge C-channel steel, with the lattice formed from 3/8 inch by 3/4 inch 14-gauge U-channel steel, assembled with zinc-plated rivets, and finished in galvanized steel with powder coat color options available on request. A padlock hasp is provided as standard, with an integrated cylinder lock available as an option to suit site security preferences.
Features:
- Combination of vertical bars and scissor gates for full coverage
- Withstands indoor and outdoor conditions including heat and chemicals
- Fixed top frame with folding bottom option
- Galvanized steel construction with optional powder coat finish
- Padlock hasp standard; integrated cylinder lock optional
- Ships unassembled for easy on-site assembly
- 6' W x 12' H overall footprint; weight 180.0 lbs each
- Width:
- 6'
- Height:
- 12'
- Max Width:
- 6'
- Folded Lattice Height:
- 12'
- Top Frame Style:
- Fixed
- Expanded Lattice Height:
- 11.5'
- Frame:
- 1-1/4 x 5/8 14 gauge C-channel steel with rubber grommet feet
- Lattice:
- 3/8 x 3/4 14 gauge U-channel steel with 1/4 x 1-1/2 zinc plated steel rivets
- Locking Options:
- Padlock hasp comes standard, integrated cylinder lock is optional
- Finish:
- Galvanized steel, powder coat colors available on request
- Top Bottom Track:
- 1-7/8 x 1-3/8 11 gauge box channel steel
- Warranty:
- 1-year manufacturer warranty
- Assembly:
- Ships unassembled
- Type:
- Storefront Security Gate - Single Gate
- Weight:
- 180.0 lbs. ea.
- Package Size:
- Each
