The Illinois Engineered Products D-59 Retractable Folding Door Gate is designed for smaller door openings where a compact, unobtrusive barrier is needed. This hinged door gate can be mounted on either the left or right side, and can be installed in the door casing or on the door face, inside or outside the jamb, to accommodate a variety of doorway configurations. When deployed, it provides a barrier that leaves the doorway opening clear for safe, unobstructed passage, while still securing the area when access is restricted.
Constructed for durability, the unit features heavy-duty galvanized steel framing and heavy U-channel webbing. The webbing is riveted back-to-back with aircraft-quality aluminum rivets, chosen to resist stress without cracking, rusting, or separation. The frame is built from 14-gauge, 1-1/2" x 1-1/2" vertical angles, with a 48" locking bar and hasp for padlock compatibility (padlock not included). The gate ships unassembled, with a galvanized finish that supports use in harsh environments and all-weather conditions, from extreme heat to ice and snow.
This gate is ideal for securing high-traffic hallways or entryways in a variety of settings where a full-width conventional gate would be impractical. Its maximum width is 48 inches, and it stacks to a 11" depth when collapsed, with a deployed height of 59" and an expanded height of 53" (note the height specifications reflect its closed and open positions). When planning installation, consider that the unit can be mounted on the jamb, casing, or door face to fit the available space and traffic flow. Custom sizing and powder coat finishes are available, though these options may affect lead time. Each unit weighs approximately 28 lbs and ships as a single package.
Features:
- Designed for smaller openings, ideal where space is limited
- Mountable on left or right side, in casing or on door face
- Heavy-duty galvanized steel construction for all-weather durability
- Heavy U-channel webbing riveted back-to-back with aircraft aluminum rivets
- Ships unassembled for easier handling and on-site assembly
- Includes 48" locking bar and padlock hasp (padlock not included)
- Width:
- Up to 48
- Height:
- 59
- Depth:
- 11 stacked
- Expanded Height:
- 53
- Collapsed Height:
- 59
- Assembly:
- Ships unassembled
- Lattice:
- Heavy-duty 12-gauge 3/4 x 3/8 steel U-channel webbing riveted back to back with aircraft quality aluminum rivets
- Frame:
- Heavy-duty14-gauge 1-1/2 x 1-1/2 vertical angles with 48 locking bar and padlock hasp Padlock not included
- Finish:
- Galvanized finish
- Type:
- Door Gate
- Weight:
- 28.0 lbs. ea.
- Package Size:
- Each
