The TCP HB15000250 is a high-efficiency LED linear high bay designed to replace 250W or 400W HID fixtures in industrial and warehouse spaces. This 150W LED unit delivers around 18,000 lumens and operates on a wide voltage range from 347V to 480V, making it suitable for many large-area lighting installations. The fixture uses a post-painted steel frame with clean edges and a rounded profile, contributing to a robust, serviceable install while maintaining a slim 23.8 inch length, 3.8 inch width, and 12.6 inch height footprint. It supports line dimming and offers optional accessory configurations such as battery backup or motion sensors, aligning with common facility management needs for energy efficiency and automated controls.
The design features a wide beam spread achieved through an angled LED arrangement, which helps create a clean cutoff that reduces glare and light spill. Built for durability, the unit is rated IP65, indicating protection against dust and water jets, making it appropriate for challenging environments. The fixture is hardwired and comes in a white finish with a 5000K color temperature, delivering a neutral daylight-like appearance that is typical for work areas and task lighting. The package includes mounting hardware such as two hanger hooks, five feet of jack chains, a hub mount kit compatible with .75 inch conduit or stem mounts, and a six-foot pre-wired cord, facilitating straightforward installation and mounting flexibility.
This TCP LED linear high bay is identified as a DLC Premium-qualified option, reflecting its compliance within certain energy-efficiency and performance programs, though exact standards applicability should be confirmed for specific projects. With a 5-year warranty and a weight of about 10 pounds, the HB15000250 provides a balance of efficiency and ease of service in large-area applications. It is suitable for installations requiring reliable illumination upgrades from legacy HID systems and offers dimming capability to support additional energy savings and lighting control strategies.
Features:
- 18000 lm at 5000K
- 150W LED, HID equivalent to 400W
- 347V-480V input, line-dimmable
- IP65 rated, steel post-painted frame
- Included: 2 Tong hangers, 5 ft. jack chains, hub mount kit, 6 ft. pre-wired cord
- Wide beam spread with clean cut-off from angled LED design
- Operating temperature -4 to 122°F
- Part Number:
- HB15000250
- Certificate:
- DLC Premium
- Color / Finish:
- White
- Color Temperature:
- 5000K
- Connection Type:
- Hardwired
- Dimmable:
- Yes
- Fixture Type:
- Linear
- IP Rating:
- IP65
- Lumens:
- 18000 lm
- Material:
- Steel
- Maximum Voltage:
- 347V-480V
- Warranty:
- 5 Yr
- Wattage:
- 150W
- Wattage Equivalent:
- 400W MH
- Weight:
- 10.00 lb
- UPC:
- 762148153931
- Package Size:
- Each
