TCP DTF4UZDA2CCT 2x4 Selectable Watt Low Bay Luminaire 35K/41K/50K

The TCP DTF4UZDA2CCT is a selectable-CCT low bay luminaire designed for ceiling-mounted applications in commercial and industrial settings. It provides the efficiency and long life of LED lighting with the flexibility to switch between correlated color temperatures (35K, 41K, or 50K) to suit task lighting or ambient needs. The luminaire uses back-lit diffusion to deliver uniform illumination across the full panel, helping to minimize hot spots and create a visually comfortable environment while reducing maintenance frequency due to its 50,000-hour rated life.

Constructed for grid ceilings, it fits standard 1-inch and 9/16-inch T-bar setups, and its slim, lightweight profile simplifies installation and handling. The unit is dimmable with 0–10 V control and operates on 120–277 V input, offering versatility for a range of electrical configurations. With color rendering and consistency designed to maintain the appearance of referenced focal points, the fixture also supports sustainability goals by delivering energy savings over traditional fluorescent alternatives and potential utility rebates where applicable. The product is mercury-free and suitable for damp locations, aligning with common facility and maintenance standards.

Practical considerations include selecting the desired CCT at install or via field configuration and planning for a long service life with minimal maintenance. The DTF4UZDA2CCT carries a 5-year warranty, reflecting TCP’s confidence in its reliability and supported performance over time. When ordering, note the model-specific characteristics—selectable CCT, low-profile form factor, and back-lit diffusion—as key differentiators that influence light quality, installation complexity, and long-term operating costs.

Features:

• Energy savings over fluorescent alternatives
• 50,000 hour rated life reduces maintenance
• Excellent color consistency and CRI >80
• Mercury-free construction
• Fits standard 1" and 9/16" T-bar grid ceilings
• Back-lit diffusion for uniform illumination
• Slim, low-profile, lightweight design
• Battery Backup is Title 20 Compliant
