The Patterson CW22B High Velocity Fan is a rugged, wall- or column-mountable airflow solution designed for demanding industrial spaces such as factories and warehouses. This 22-inch, direct-drive fan is built with a high-impact polypropylene housing and heavy-gauge steel components, paired with a patented Venturi-style barrel and side air inlets to project and entrain air effectively across open areas like aisles, workstations, and staging zones. The unit is available in multiple voltages (115V–460V) and can be fitted with varied speed options, offering flexibility to match cooling and ventilation needs without sacrificing performance. The 21-inch propeller diameter, 3-blade galvalume construction, and totally enclosed, maintenance-free motor with sealed bearings contribute to reliable operation in industrial environments. A 12-foot power cord is included when used with 115V power, and OSHA-compliant steel finger guards provide a measured level of safety for operators in proximity to moving air.
Features:
- 21" (approx) 3‑blade propeller for high airflow
- High-impact polypropylene housing with heavy-gauge steel construction
- Patented Venturi-designed barrels for efficient cooling
- OSHA-compliant steel finger guards
- Multiple voltages: 115V–460V; direct-drive, maintenance-free motors
- Eight mounting options; optional oscillator kits
- 12’ power cord (115V only); 2-year warranty
- Propeller:
- 21” Diameter, 3-Blade Galvalum, 19°
- Fan Inlet/Outlet:
- High-Impact Polypropylene
- Finger Guards:
- OSHA-Compliant
- Power Cord (115V Only):
- 12’ Length (Switch Optional)
- RPM:
- 1725
- Decibels:
- 66.5 @ 20’ - 77.6 @ 3’
- Coverage:
- 3600 ft²
- Warranty:
- 2 Years
- CFM:
- 5570
- HP:
- 1/2
- Width:
- 29”
- Depth:
- 16”
- Air Throw:
- 100’
- Weight:
- 49 lbs
- Package Size:
- Each
