The Illinois Engineered Products SSG780-ANG Retractable Folding Gate is designed to secure openings such as loading docks, garage and service doors, hallways, and entryways while preserving visibility and airflow. This single-gate unit uses a heavy-duty 12-gauge steel vertical frame with 14-gauge steel webbing, finished in galvanized coating for durability and easy maintenance. When deployed, the gate reduces height by six inches compared to its collapsed state, and it retracts on its mounts to move completely out of the way, minimizing obstruction when access is required.
Constructed to withstand industrial use, the gate features rugged components including solid steel casters and bearing hardware, with mounting brackets included for straightforward installation. The lattice consists of heavy-duty 14-gauge steel U-channel webbing riveted with aircraft-quality aluminum rivets, delivering a secure yet lightweight barrier that still allows light and air to pass through the opening. Please note that lag bolts and a padlock are not included, but the system offers a padlock hasp and a lockable drop pin for controlled access.
This model covers width ranges from 6' to 7' and has a collapsed height of 8' with an expanded height of 7'6". It ships unassembled, so on-site setup and alignment are part of the installation process. The galvanized finish provides rust resistance and easier cleaning, and optional custom powder coating is available upon request. Suitable for facilities seeking a retractable solution that balances security with visibility and ventilation, it enables controlled access without permanently occupying floor space.
Features:
- Secure doors, hallways, and entryways while allowing light and air circulation
- Heavy-duty 12-gauge steel vertical frame with 14-gauge steel webbing
- Galvanized finish for durability and ease of cleaning
- Retracted gate pivots to move completely out of the way
- Height: 7'6" expanded, 8' collapsed
- Includes mounting brackets, bearing washer, and solid steel caster
- Width:
- 6' to 7'
- Height:
- 8'
- Depth:
- 11 stacked
- Fits Widths:
- 6' to 7'
- Expanded Height:
- 7' 6
- Collapsed Height:
- 8'
- Frame:
- Heavy-duty 12-gauge 1-1/2 x 1-1/2 vertical angles
- Caster:
- Solid steel
- Finish:
- Galvanized finish, custom powder coating is also available, consult us for details
- Lattice:
- Heavy-duty 14-gauge steel U-channel webbing riveted back to back with aircraft quality aluminum rivets
- Type:
- Single Gate
- Assembly:
- Ships unassembled
- Weight:
- 90.0 lbs. ea.
- Package Size:
- Each
