The Illinois Engineered Products SSG475-ANG Retractable Folding Gate is designed to secure openings like loading docks, hallways, and entryways while preserving visibility, air movement, and access. This single-gate unit features a heavy-duty 12-gauge steel vertical frame with 14-gauge steel webbing, finished in galvanized coating for durability, rust resistance, and easier cleaning. When retracted, the gate pivots on its mounts to move completely out of the way, helping to minimize obstruction during times when access is needed. The assembled package includes mounting brackets, bearing washer, and a solid steel caster, with lag bolts and padlock not included, allowing you to tailor installation to your space.
Designed to fit openings 3 ft to 4 ft wide, the gate stands 7 ft 6 in tall when collapsed and 7 ft tall when extended, with a total stack depth of 11 in. The lattice is constructed from heavy-duty 14-gauge steel U-channel webbing riveted back-to-back with aircraft-quality aluminum rivets, and the vertical frame uses 1-1/2 in by 1-1/2 in heavy-duty angles for added rigidity. A galvanized finish provides corrosion resistance and ease of cleaning, with custom powder coating options available upon request.
Its intended use includes securing receiving doors, lift-up doors, hallways, and entryways where you still want light and air to circulate. While the product ships unassembled, following the included installation hardware and mounting brackets will help ensure a stable, secure installation. Be mindful that the gate’s height decreases by 6 in when extended, a consideration for door clearance and headroom in tight spaces. Compatibility notes include the 3–4 ft width range and the requirement for appropriate hardware (padlock applies to security, but is not included).
Features:
- Secure doors, hallways, and entryways while allowing light and air circulation
- Heavy-duty 12-gauge steel vertical frame with 14-gauge steel webbing
- Galvanized finish for durability, rust resistance, and easy cleaning
- Retracted gate pivots to move completely out of the way
- Height: 7'6" collapsed, expands to 7' tall
- Includes mounting brackets, bearing washer, and solid steel caster; lag bolts and padlock not included
- Width:
- 3' to 4'
- Height:
- 7' 6
- Depth:
- 11 stacked
- Fits Widths:
- 3' to 4'
- Expanded Height:
- 7'
- Collapsed Height:
- 7' 6
- Frame:
- Heavy-duty 12-gauge 1-1/2 x 1-1/2 vertical angles
- Caster:
- Solid steel
- Finish:
- Galvanized finish, custom powder coating is also available, consult us for details
- Lattice:
- Heavy-duty 14-gauge steel U-channel webbing riveted back to back with aircraft quality aluminum rivets
- Type:
- Single Gate
- Assembly:
- Ships unassembled
- Weight:
- 64.0 lbs. ea.
- Package Size:
- Each
