The Illinois Engineered Products PFG1685-ANG retractable double folding gate provides secure access control for loading docks, garages, hallways, and entryways while preserving visibility, airflow, and ease of movement. This gate configuration is designed to cover 14 to 16 feet of width and stands 8 feet 6 inches when folded, expanding to 8 feet in height. Its double-gate arrangement folds and pivots on sturdy mountings, allowing the gate to swing out of the opening when not in use, which helps maintain clear access without obstructing traffic or light.
Constructed for durability, the gate uses a heavy-duty 12-gauge steel vertical frame paired with 14-gauge steel webbing, all finished in galvanized steel for rust resistance and easier cleaning. The lattice is built from 14-gauge steel U-channel webbing riveted with aircraft-grade aluminum rivets, providing structural rigidity while keeping weight manageable. Each unit ships unassembled with mounting brackets, bearing washers, and solid steel casters included; lag bolts and padlocks are not included, allowing you to choose your own locking and mounting hardware to match your security and installation requirements. The design accommodates easy installation and field adjustments as needed.
This double gate is suited for securing receiving doors, lift-up doors, hallways, and entryways where maintaining light and air flow is important. The gate’s height reduction of 6 inches when extended is a key consideration for fit within fixed vertical clearances. Consider your site’s mounting surface, load requirements, and whether custom powder coating is desired for additional corrosion resistance; custom powder coating is available upon consultation. The unit is packaged as a single, unassembled gate per package, with an approximate weight of 185 lbs per gate, reflecting its robust construction without compromising operability.
Features:
- Secure openings while allowing airflow and light
- Heavy-duty 12-gauge steel frame with 14-gauge webbing
- Galvanized finish for durability and easy cleaning
- Folded gates pivot to move completely out of the way
- Height: 8' expanded, 8'6" collapsed; width: 14'–16'
- Includes mounting brackets, bearing washers, and solid steel casters
- Does not include lag bolts or padlocks
- Width:
- 14' to 16'
- Height:
- 8' 6
- Depth:
- 15 stacked per side
- Fits Widths:
- 14' to 16'
- Expanded Height:
- 8'
- Collapsed Height:
- 8' 6
- Frame:
- Heavy-duty 12-gauge 1-1/2 x 1-1/2 vertical angles.
- Casters:
- Solid steel
- Finish:
- Galvanized finish, custom powder coating is also available, consult us for details
- Lattice:
- Heavy-duty 14-gauge steel U-channel webbing riveted back to back with aircraft quality aluminum rivets
- Type:
- Double Gate
- Assembly:
- Ships unassembled
- Weight:
- 185.0 lbs. ea.
- Package Size:
- Each
