The Illinois Engineered Products HYDS711 storefront security gate is a full-width, modular barrier designed to secure open storefronts, warehouse entries, or restricted areas quickly and with minimal installation. This single-gate system spans 7 feet in width and stands 11 feet high, providing continuous coverage when extended and retracts smoothly as needed. Its construction combines vertical bars that ride in tracks with a scissor lattice, delivering a robust barrier intended to deter partial and full access while allowing easy operation for authorized movement of personnel or equipment.
The gate uses a galvanized steel frame and lattice components, assembled with durable hardware and a 1-1/4" x 5/8" 14-gauge C-channel steel frame paired with 3/8" x 3/4" 14-gauge U-channel lattice and rivets. A padlock hasp is included as a standard locking option, with an integrated cylinder lock available as an upgrade. The system ships unassembled and is suited for both indoor and outdoor environments, with options for top and bottom track styles and powder coating in colors beyond the standard galvanized finish. A 1-year manufacturer warranty accompanies the unit to cover manufacturing defects.
Ideal use cases include sectioning off storefronts, securing inventory pathways, or creating controlled access in warehouses or production facilities. Given its size, consider doorway or aisle configurations and ensure mounting surfaces can accommodate the top and bottom tracks. This model weighs approximately 193 lbs per unit, so plan for appropriate handling and installation. The HYDS711 is designed to be non-returnable as part of its purchase terms and emphasizes straightforward assembly and reliable operation in varied conditions, including exposure to heat, rain, snow, and typical industrial cleaners.
Features:
- Combination of vertical bars and scissor gates for complete coverage
- All-weather design suitable for indoor and outdoor use
- Fixed top track with folding bottom option
- Heavy-duty 14 gauge steel construction with durable z-bar rivets
- Padlock hasp standard; integrated cylinder lock option available
- Galvanized finish with optional powder coat colors
- Ships unassembled, 1-year manufacturer warranty
- Width:
- 7'
- Height:
- 11'
- Max Width:
- 7'
- Folded Lattice Height:
- 11'
- Top Frame Style:
- Fixed
- Expanded Lattice Height:
- 10.5'
- Frame:
- 1-1/4 x 5/8 14 gauge C-channel steel with rubber grommet feet
- Lattice:
- 3/8 x 3/4 14 gauge U-channel steel with 1/4 x 1-1/2 zinc plated steel rivets
- Locking Options:
- Padlock hasp comes standard, integrated cylinder lock is optional
- Finish:
- Galvanized steel, powder coat colors available on request
- Top Bottom Track:
- 1-7/8 x 1-3/8 11 gauge box channel steel
- Warranty:
- 1-year manufacturer warranty
- Assembly:
- Ships unassembled
- Type:
- Storefront Security Gate - Single Gate
- Weight:
- 193.0 lbs. ea.
- Package Size:
- Each
