The Vestil TM-40-DC Tilt Master is a DC-powered tilt and transport unit designed to lift, tilt, and reposition filled tote boxes or baskets without relying on a fork truck or lift table. With a compact profile and a 4000 lb uniform capacity, this tilter can function as a mobile transporter, moving completed loads between workstations to streamline workflow. It features a foldable ergonomic push handle that tucks away when not in use, helping to maintain clear access to the load and reducing interference during operation. The device uses a 12V DC motor and includes an on-board battery charger and battery charge indicator, ensuring the unit is ready for use and can be maintained with minimal downtime. The tilt capability reaches up to 90°, enabling ergonomic loading and access from a variety of angles, which can help reduce user strain when handling tall or awkwardly sized totes.
Features:
- Transporter design to move completed products between workstations without a forklift
- Two rigid and two swivel casters for smooth mobility
- 90° tilt angle for ergonomic access to loads
- Ergonomic push handle folds down when not in use for better access
- 12V DC powered tilt for controlled operation
- Fixed fork adjustment at 26 inches (OD) with a 4000 lb capacity
- Color:
- Blue
- Material:
- Steel
- Uniform Capacity (lb.):
- 4000
- Fork Adjustment (in.):
- Fixed at 26 (OD)
- Operator Reach (in.):
- 7-1/4
- Fork Width (in.):
- 6
- Fork Length (in.):
- 38-1/8
- Rotated Height (in.):
- 33
- Lowered Height (in.):
- 3-5/8
- Maximum Tilt Degree:
- 90
- Power:
- 12V DC
- Wheel Diameter (in.):
- 8
- Wheel Width (in.):
- 3
- Wheel Type:
- Phenolic
- Folding Handle Length (in.):
- 20
- Load Center (in.):
- 20
- Package Size:
- Each
