The Vestil CART-1000D-DC is a DC-powered hydraulic elevating cart designed to move and lift loads with an ergonomic, one-button operation. Its platform is raised and lowered by a built-in hydraulic system powered by a 12V battery, allowing operators to adjust work height without manual lifting. The unit is built on a steel frame and rolls on a four-caster configuration featuring two rigid and two swivel polyurethane casters, which facilitates portability and maneuverability even when the cart is loaded.
Key construction details include a double scissor design that provides a substantial lift range from a lowered height of 19-1/2 inches to a raised height of 63-3/4 inches. The platform dimensions measure 39-3/4 inches in length by 20-1/2 inches in width, offering a practical surface for transporting medium-duty loads. The cart includes an internal safety velocity fuse within each cylinder for added protection during operation, and comes equipped with an onboard battery charger and battery charge indicator gauge for convenient power management. The color is yellow, and the overall design emphasizes rugged steel construction to support a uniform 1000 lb capacity.
This model is suitable for environments where quick, ergonomic material handling and height-adjustable access are beneficial. It can be used for loading and unloading parts, raising items to workstation heights, or moving totes and assemblies across shop floors. Consider battery maintenance and charger accessibility to ensure consistent performance, and note the caster configuration supports smooth movement when loaded, while the polyurethane wheels help protect floor surfaces.
Features:
- Unique lift design quickly raises & lowers material
- Ergonomic cart design improves user safety
- Caster construction provides easy portability when loaded
- Steel construction offers long lasting rugged use
- Double scissor design for stable vertical movement
- Powered by one 12V battery
- Four polyurethane casters for smooth travel
- Color:
- Yellow
- Material:
- Steel
- Uniform Capacity (lb.):
- 1000
- Platform Width (in.):
- 20-1/2
- Platform Length (in.):
- 39-3/4
- Lowered Height (in.):
- 19-1/2
- Raised Height (in.):
- 63-3/4
- Scissor Design:
- Double
- Battery Quantity/Voltage:
- (1) 12V
- Caster Quantity/Diameter/Width (in.):
- (4) 6 x 2
- Caster Material:
- Polyurethane
- Package Size:
- Each
