The Patterson V12B-230 V-Series Big HVLS Ceiling Fan is a high-capacity, ceiling-mounted air mover designed to circulate large volumes of air in industrial and commercial spaces. With a 12-foot diameter and five contoured blades, it delivers broad coverage while directing air downward through wingtip design to minimize losses at the blade tips. The direct-drive motor configuration eliminates gears, reducing maintenance requirements and contributing to a lower overall weight compared with gearbox-driven alternatives. The unit operates on 208–230V three-phase power and offers forward, reverse, and variable-speed control to adapt air movement for different seasons and occupancy patterns. Its reputable performance is complemented by a quiet operation profile, rated at under 42 decibels, making it suitable for environments where noise is a concern. The V-Series is engineered for resilience in demanding settings and features a multi-tier safety system to support reliable operation in industrial spaces.
This HVLS fan is designed to push air across substantial areas, with an indicated industrial reach of up to 70 feet (spacing) and a maximum effective coverage of roughly 11,180 square meters (12,035 square feet). While suitable for indoor and covered outdoor spaces, installation should consider mounting height and clearances to maximize airflow and minimize disruption. The fan’s heft and mounting requirements reflect its big-air performance, so proactive planning for mounting structure, electrical provisions, and service access will help ensure dependable long-term operation. The V-Series model is positioned as a cost-effective, long-term airflow solution that can contribute to improved comfort, moisture management, and potential energy savings through more efficient space heating and cooling strategies.
Features:
- Direct Drive: zero gears means zero maintenance
- Wingtips reduce airflow loss and direct air downward
- Blades contoured for maximum air movement
- Lightweight design due to no gearbox
- Sound under 42 decibels for sound-sensitive environments
- Forward, Reverse and Variable Speed
- IP66 VFD and IP54 motor protection for indoor/outdoor covered spaces
- Multiple safety protection tiers
- Size:
- 12 ft Diameter
- Number of Blades:
- 5
- Industrial Spacing:
- 70 ft (21.3 m)
- Max Effective Area:
- 12035 ft² (1118 m²)
- Max RPM:
- 80 RPM
- Hanging Weight:
- 92 lbs (42 kg)
- Motor:
- 1 HP (0.7 kW)
- Voltage:
- 208-230V Three-Phase
- Package Size:
- Each
