The Illinois Engineered Products XL1265CUS Portable Folding Gate is a heavy-duty temporary barrier designed for adaptable access control in facilities. When opened, this starter unit expands to reach up to 12 feet, enabling rapid sealing of hallways, doorways, or other openings while allowing air and light to pass through. When not in use, the gate folds for compact storage and can be rolled to a convenient location for quick re-deployment, making it suitable for facilities that require flexible, temporary security solutions.
Construction details emphasize a robust, factory-installed starter gate paired with adders to create a barrier exactly how wide you need it. The system features a 3-inch caster-equipped collapsed height of 78 inches, facilitating easy movement and positioning. The lattice and frame components use galvanized and zinc-plated steel builds, with a design that accommodates wall-mount or floor-mount attachment in extended configurations. A padlock hasp is included to secure the barrier when in use, helping to deter tampering while the gate is deployed.
Practical use cases span schools, offices, warehouses, factories, and retail stores—anywhere temporary, controllable access is required without obstructing airflow or visibility. Note that product specifications indicate the setup supports a 50-foot width in its current configuration, with the option to add 6-foot adders to extend coverage as needed. This model ships unassembled and requires assembly upon installation, aligning with large-width, heavy-duty gate deployments that demand custom-length barriers. For maintenance and handling, ensure casters and locking features are kept clean and functional to preserve ease of movement and security when deployed.
Features:
- Instant security for openings up to 50' wide
- Starter gate expands to 12'; adders extend as needed
- Folds and rolls away for storage
- 78" collapsed height with 3" casters for easy mobility
- Padlock hasp included for locking
- Heavy duty design; wall-mount attachment available
- Width:
- Up to 50'
- Height:
- 6'
- Fits Widths:
- 12'
- Expanded Height:
- 6'
- Collapsed Height:
- 6' 6
- Type:
- Heavy duty, starter
- Attachment:
- Wall
- Lattice:
- 3/8 x 3/4 14 gauge galvanized with 3/16 x 1/2 zinc plated steel rivets
- Frame:
- 1-1/2 x 1-1/2 12 gauge zinc plated angle iron
- Axle:
- 28 wide w/ 2 casters 3 dia w/ 12 gauge CRS brackets in channel construction and zinc plated
- Support Bars:
- 3/4 galvanized round tubing
- Transport Strap:
- 17 gauge U-channel welded to axle
- Locking Bar Wall Mount:
- 18 gauge, 3/16 zinc plated angle iron
- Assembly:
- Ships unassembled
- Casters:
- 3 Rubber Locking
- Weight:
- 135.0 lbs. ea.
- Package Size:
- Each
