Dräger 8103591 Gas Detector Tube is a disposable glass tube used with a Dräger tube pump to detect and quantify methylene chloride vapors in air. The tube is designed for colorimetric reading over a defined exposure range, enabling quick, on-site evaluation of solvent vapors in occupational environments. This package contains a box with 10 tubes, each configured to measure a standard range of 20 to 200 ppm and with a typical measurement time of 7 minutes, helping technicians obtain timely results during air monitoring tasks.
The tube construction uses glass as the primary sensing medium, with a break-off tip to facilitate safe opening and draw of a sample into the tube for analysis. The 20–200 ppm range specifies the detectable concentration window for methylene chloride, providing a balance between sensitivity and practicality for routine workplace assessments. The box quantity of 10 tubes supports small- to mid-scale testing programs and allows for multiple sampling points or repeat measurements without frequent restocking.
When using these tubes, it is important to follow the manufacturer’s indicated measurement time and sampling procedure to ensure consistent results. Compatibility is limited to Dräger tube pumps designed for these diffusion-type gas detector tubes. Because product data and performance specifications are provided by the manufacturer, users should refer to the Dräger product documentation for exact handling instructions, storage conditions, and replacement intervals to maintain accuracy.
Features:
- Measuring range: 20–200 ppm
- Measurement time: ~7 minutes
- Gas detected: Methylene Chloride 20/a
- Tube material: Glass
- Break-off tip: Yes
- Package size: Box
- Box quantity: 10 per box
- Gas Detected:
- Methylene Chloride 20/a
- Standard Range Of Measurement:
- 20 - 200 ppm
- Measurement Time:
- 7 Min
- Tube Material:
- Glass
- Break-Off Tip:
- Yes
- Package Size:
- Box
- Box Quantity:
- 10/Box
