The Draeger 6728981 Gas Detector Tube is a single-use, glass-tiber reaction tube designed for qualitative to semi-quantitative measurement of mercaptan vapors in air. When used with a compatible Draeger tube pump, the tube provides a practical method for detecting mercaptan concentrations in the 0.5 to 5 ppm range. Each tube is configured for a specified measurement time, enabling a repeatable snapshot of gas presence during a defined sampling period.
Constructed as a glass detector tube with a break-off tip, this package is supplied as a box containing multiple tubes. The product is specified for a 0.5–5 ppm range, with a typical measurement duration of 5 minutes per test. The box quantity is 10 tubes, making it suitable for routine field checks or temporary testing campaigns where mercaptan monitoring is required.
Mercaptans are sulfur-containing compounds commonly encountered in odorization processes or certain industrial environments. The Tube and pump method delivers an on-site, direct reading without complex instrumentation, though it is subject to factors such as flow rate, ambient conditions, and chemical sensitivity. Ensure proper training and follow the manufacturer’s procedure for consistent results, including correct tube storage, handling, and timely analysis after activation.
Features:
- Gas Detected: Mercaptan 0.5/a
- Standard Range: 0.5 - 5 ppm
- Measurement Time: 5 minutes
- Tube Material: Glass
- Break-Off Tip: Yes
- Package Size: Box
- Box Quantity: 10 per box
- Gas Detected:
- Mercaptan 0.5/a
- Standard Range Of Measurement:
- 0.5 - 5 ppm
- Measurement Time:
- 5 Min
- Tube Material:
- Glass
- Break-Off Tip:
- Yes
- Package Size:
- Box
- Box Quantity:
- 10/Box
