The Light Efficient Design LED-8024E345-G7-FW is a multi-wialect LED post-top retrofit lamp designed to replace HID sources in outdoor or indoor post-top fixtures. This ballast-bypass, E26 medium-base lamp supports wattage selection (35, 45, or 60 watts) and offers selectable color temperatures (3000K, 4000K, or 5000K), enabling you to tailor light output to the task and environment. With a claimed 8,870 lumens and a high efficacy around 148 lm/W, the design seeks to maintain near-full lumen output across its 50,000-hour rated life, while operating within a wide voltage range of 120–277V. A key feature is its multi-directional mounting capability and compatibility with enclosed fixtures and damp locations, expanding where it can be installed without sacrificing performance. The lamp integrates proactive cooling through an internal fan and dynamic temperature control, which helps manage heat in confined fixtures and supports stable light output over time. It also provides protection against moisture and vibration, and includes dual-stage MOV plus surge protection for added electrical resilience. The product is designed for ballast bypass operation (Type B) and is DLC standard, indicating alignment with certain energy and performance criteria used in specifier and procurement workflows. A lightweight form factor with a 7.2-inch length and 3.4-inch diameter helps it fit a range of post-top housings, while universal orientation supports base-up, base-down, or side mounting to suit installation constraints.
Features:
- 120-277V operation
- E26 medium base
- Type B - ballast bypass
- Wattage selectable: 35W, 45W, or 60W
- CCT selectable: 3000K, 4000K, 5000K
- Replaces up to 320W HID lamps
- Damp location rated and enclosed fixture rated
- Active cooling with built-in fan
- Multi-directional mounting
- Dual stage MOV protection with 6kA surge protection
- Pretested drivers prior to shipping
- Operating temp: -40°F to 122°F
- DLC Standard
- 50,000 hour rated
- Brand:
- Light Efficient Design
- Manufacturer Part Number:
- LED-8024E345-G7-FW
- UPC:
- 844006060718
- Lumens:
- 8,870 Lumens
- Lumens Per Watt:
- 147.83
- Wattage:
- 60 Watts
- Input Voltage:
- 120-277V
- Color Temperature:
- 3000K, 4000K, 5000K
- Installation Orientation:
- Universal
- Lamp / Base Type:
- E26 Medium
- Lamp Shape:
- Corn Cob
- Rated Hours:
- 50,000 Hours
- Equivalent:
- 320W HID
- Min Operating Temp:
- -40 Degrees F
- CRI:
- 80+
- Special Features:
- CCT Selectable, Enclosed Fixture Rated, Wattage Selectable
- Length:
- 7.2
- Diameter:
- 3.4
- Package Size:
- Each
