The Worldwide Material Handling 42" D x 46" W Flared Channel Grey Waterfall Wire Mesh Deck is designed to upgrade pallet rack systems with a durable, mesh-based solution. This welded wire decking provides an open mesh pattern that enhances visibility, improves light diffusion, and helps reduce dust buildup at storage levels while supporting palletized loads. The design integrates into pallet rack beams without tools, resting securely to create an added storage tier that can accommodate varying warehouse workflows.
Key construction features include a standard 2 1/2" x 4" x 6 ga. wire mesh pattern and 14 ga. or 16 ga. support channels, with a 11/2" front and rear waterfall to help align and contain loads. The deck is finished with a durable powder coat, with an electrogalvanized option available, and is manufactured in accordance with ANSI MH26.2. These details matter for long-term performance in material handling environments where load distribution, corrosion resistance, and alignment with rack geometry are critical considerations.
Recommended for use in pallet rack applications where stronger, safer alternatives to wood decking are desired, this deck supports uniform distributed loads and is designed to fit a range of pallet sizes and configurations. Custom designs and sizes are available to match specific rack setups, and optional accessories such as snap-in, hanging, and flue dividers can be added to tailor the solution to particular storage needs. This product is listed as having a 2,500 lb capacity, with a typical lead time of 2–4 weeks, which may impact project planning and replenishment timelines.
Features:
- Standard wire mesh pattern: 2 1/2" x 4" x 6 ga.
- Support channels: 14 ga. or 16 ga.
- Front/rear waterfall: 1 1/2"
- ANSI MH26.2 compliant
- Durable powder coat finish
- Electrogalvanized finish option
- Capacity: 2,500 LBS (UDL)
- Capacity:
- 2,500 LBS
- Package Size:
- Each
