The Patterson FHVTCD-IDL-SWITCH Loading Dock Fan is a high-velocity ceiling-mount solution designed to purge trailer interiors quickly during manual loading and unloading. It delivers robust airflow to refresh warm trailers and reduce heat buildup, featuring a compact footprint that minimizes obstruction at the dock while still providing strong cooling performance. The unit integrates a 15-watt LED dock light option and a convenient 4-way switch on the power cord, enabling control of both fan and lighting functions from a single location, which can streamline dock operations.
Features:
- Purge 53' Truck Trailer in Minutes
- Dominates Airflow, Not Your Budget
- More CFM Than Other Dock Fans
- Compact Design for Clearance
- Integrated LED Dock Lights (15W) Optional
- 277V Operation with Switch Option
- Yoke Mount for Flexible Installation
- Wheel (Blower):
- 9.5 inches x 11 inches
- Fan Housing:
- High Impact Polypropylene
- Inlet Guards:
- .5 inches Opening
- Outlet Guards (optional):
- .5 inches Opening
- RPM:
- 1075
- Decibels:
- 75 @ 3'
- Enclosure:
- ODP Standard
- Frame:
- 48
- Ambient Temperature:
- 104°F
- Duty Cycle:
- Continuous
- Integrated LED Dock Lights:
- 15W (optional)
- Package Size:
- Each
