The TCP HB15000150LS1 is a 150-watt, linear LED high bay designed to replace 250–400W HID fixtures in industrial and commercial spaces. This 5000K daylight-white luminaire delivers a high luminous output suitable for overhead mounting in warehouses, manufacturing floors, and large retail settings. It is designed for hardwired connection and operates within a wide voltage range of 120V–277V, supporting line dimming and accommodating options like battery back-up or motion sensors to fit specific control strategies and code requirements.
Constructed with a post-painted steel frame, the unit emphasizes robust build quality with a clean, rounded-edge profile and a seamless finish. The housing contributes to durability and helps manage heat in demanding environments. The fixture includes practical mounting and mounting accessories: two hangers, a 5 ft. chain, hub mount kit for conduit or stem mounting, and a 6 ft. pre-wired cord, simplifying installation in variable ceiling configurations. With an IP65 rating, it is protected against dust and water ingress, supporting use in potentially damp or dusty industrial spaces. The fixture emits 18,000 lumens, delivering broad, even coverage with a wide beam spread enabled by the angled LED design for a clean light cut-off.
This TCP high bay is available in a white finish and carries a DLC Premium certification, indicating qualifying performance for certain energy rebate programs. The unit weighs 10 lb and carries a five-year warranty, reflecting TCP’s commitment to product reliability. When planning retrofits or new installations, verify mounting method, dimming compatibility, and ambient temperature requirements to ensure optimal performance within the specified -4 to 122°F operating range. Typical maintenance considerations include periodic cleaning of the lens and ensuring wiring connections remain secure, especially in environments with dust or vibration.
Features:
- LED high bay, 150W with 18,000 lm output
- 5000K color temperature for bright, neutral illumination
- IP65 rated for dust and water resistance
- Dimmable and hardwired, 120V-277V operation
- Includes installation hardware: 2 tongue hangers, 5 ft chains, hub mount kit, 6 ft cord
- Wide beam with clean cut-off from angled LED design
- Wattage equivalent to 400W HID, suitable for retrofit projects
- Part Number:
- HB15000150LS1
- Certificate:
- DLC Premium
- Color / Finish:
- White
- Color Temperature:
- 5000K
- Connection Type:
- Hardwired
- Dimmable:
- Yes
- Fixture Type:
- Linear
- IP Rating:
- IP65
- Lumens:
- 18000 lm
- Material:
- Steel
- Maximum Voltage:
- 120V-277V
- Warranty:
- 5 Yr
- Wattage:
- 150W
- Wattage Equivalent:
- 400W MH
- Weight:
- 10.00 lb
- UPC:
- 762148150756
- Package Size:
- Each
