The LED-8019E345-G3 is a high-output LED A23 replacement lamp designed to upgrade HID fixtures to energy-efficient LED performance. With an E26 medium base and a frosted lens, this lamp delivers broad, even light distribution suitable for post-tops, bollards, low-bay, and high-ceiling downlight applications. It is rated for damp locations and enclosed fixtures, and it carries an IP64 ingress protection rating, making it a practical option for areas where moisture and dust exposure are a concern. The lamp is CCT-selectable, offering three color temperature options (3000K, 4000K, and 5000K) to match desired ambiance and application needs, and it operates over a wide voltage range of 120–277V. Aiming for energy savings, the device is equivalent in light output to traditional 300W incandescent/higher-output HID installations while consuming just 35W, and it is designed to deliver up to 50,000 hours of service life under typical operating conditions. The unit includes built-in, pretested and potted drivers that are burn-in tested and protected against vibration and moisture, contributing to reliability in challenging environments. The product supports dimming via side switch with stepped LED control, enabling a simple pathway to energy reduction in appropriate installations. While marketed as suitable for enclosed fixtures and dimming capabilities, users should verify compatibility with specific ballast-free HID retrofit applications and any wired communication protocols that may govern dimming behavior.
This lamp is intended for use in commercial and industrial lighting scenarios where high lumen output is required from a compact A23 form factor. Its 4,550–4,725 lumen range (depending on color temperature) and 3,000–5,000K selectable white light provide flexible lighting options for site照 selection and visual task performance. The lamp’s comparable performance to a 200–300W HID source makes it a straightforward upgrade path for facilities looking to reduce energy consumption while maintaining broad, even illumination. Packaging is described as a single unit per package.
Features:
- 120-277V operation
- CCT-selectable: warm 30K, neutral 40K, or daylight 50K
- Side-switch dimming (50% max) with stepped dimming via other protocols
- Equivalent to 300W incandescent
- Frosted lens to reduce glare
- E26 medium base
- Damp location rated
- Enclosed fixture rated
- IP64 rated
- Energy Star
- 50,000-hour rated
- Brand:
- Light Efficient Design
- Manufacturer Part Number:
- LED-8019E345-G3
- UPC:
- 844006080198
- Lumens:
- 4,550 Lumens
- Wattage:
- 35 Watts
- Input Voltage:
- 120-277V
- Color Temperature:
- 3000K, 4000K, 5000K
- Color:
- Frosted
- Lamp / Base Type:
- E26 Medium
- Lamp Shape:
- A21
- Rated Hours:
- 50,000 Hours
- Equivalent:
- 300W Incandescent
- Min Operating Temp:
- -40 Degrees F
- CRI:
- 80+
- Special Features:
- CCT Selectable, Enclosed Fixture Rated, Energy Star Rated
- Length:
- 7.1
- Diameter:
- 3.9
- Package Size:
- Each
