Light Efficient Design’s LED-8130M40D is a high bay retrofit lamp designed to replace a 400W HID in open fixtures and damp locations. With a 150W LED rating and an integrated ring of uplight, this EX39 Mogul base lamp delivers brightness equivalent to traditional HID sources while supporting a quieter, fanless operation. The unit is built around a USA-designed driver that is pretested and burnt in three times before shipping, and it includes protective measures such as dual-stage MOV surge protection and moisture/vibration resistance. Its claim to damp location and open fixture suitability makes it a practical option for warehouses, manufacturing floors, and other industrial spaces where reliable, long-life illumination is needed.
The LED-8130M40D operates on 120–277V with 0–10V dimming, enabling straightforward integration into existing lighting circuits with a ballast-bypass configuration (Type B). It is rated for 50,000 hours of operation, and the color temperature is specified at 4000K, providing a neutral daylight-like ambience suitable for task lighting. The lumens output is listed at 20,900, contributing to high ambient brightness while maintaining a compact form factor (8.7 in diameter, 10 in height). The design emphasizes durability and vibration resistance, making it a robust option for facilities subject to movement or impact.
When considering installation, note that this lamp is intended for open fixtures and damp locations, and it requires an EX39 Mogul socket. It’s important to verify fixture compatibility, electrical wiring for ballast bypass, and mounting orientation to maximize the integrated uplight feature. Replacement cycles can be informed by the 50,000-hour rating, though real-world performance will depend on operating conditions, duty cycle, and ambient temperatures.
Features:
- 120-277V / Type B ballast bypass
- 0-10V dimmable
- Equivalent to 400W HID fixtures
- Mogul EX39 base
- Includes ring of uplight
- Fanless design for silent operation
- Dual stage MOV protection with 10kA surge protection
- Damp location and open fixture rated
- USA designed and specified LED driver with burn-in testing
- Brand:
- Light Efficient Design
- Manufacturer Part Number:
- LED-8130M40D
- UPC:
- 844006077624
- Lumens:
- 20,900 Lumens
- Wattage:
- 150 Watts
- Input Voltage:
- 120-277V
- Dimmable:
- 0-10V
- Color Temperature:
- 4000K
- Lamp / Base Type:
- EX39 Mogul
- Rated Hours:
- 50,000 Hours
- Equivalent:
- 400W HID
- Min Operating Temp:
- -40 Degrees F
- CRI:
- 80+
- Diameter:
- 8.7
- Height:
- 10
- Package Size:
- Each
