The Patterson PB26B High Velocity Fan is a heavy-duty, pedestal-mounted workstation fan designed to move substantial air in industrial settings. With a 26-inch, three-blade propeller and a venturi-style barrel design, this unit concentrates airflow to project and entrain air across long distances, making it suitable for aisles, workstations, pick modules, and shipping/receiving zones where effective ventilation and cooling can impact productivity and comfort.
Constructed around high-impact polypropylene (HIPP) housing and heavy-gauge steel components, the PB26B combines durability with a compact stand. The fan carries a direct-drive, maintenance-free motor with sealed bearings and options for multiple voltages (115V–460V) and variable-speed configurations (14
Features:
- 10" - 34" diameters
- Fan Housing: High-impact polypropylene (HIPP) & heavy-gauge steel construction
- Patented Venturi-designed barrels
- Side air intakes
- Custom-spec, direct drive, maintenance-free motors with long-lasting sealed bearings (totally enclosed)
- Multiple voltages: 115V - 460V
- Available variable speed motors (14" - 22")
- Eight mounting options
- Optional oscillator kits
- OSHA-compliant steel finger guards
- 12’ power cord (115V only)
- 2-year warranty <
- Propeller:
- 26” Diameter, 3-Blade Galvalum, 18°
- Fan Inlet/Outlet:
- High-Impact Polypropylene
- Finger Guards:
- OSHA-Compliant
- Power Cord (115V Only):
- 12’ Length (Switch Optional)
- RPM:
- 1800 (standard)/ 1200 (optional)
- Decibels:
- 80.8 @ 20’ - 85.2 @ 3’ (1800)/ 75.7 @ 20' - 81.3 @ 3' (1200)
- Coverage:
- 6100 ft²
- Warranty:
- 2 Years
- CFM:
- 7650
- HP:
- 1
- Width:
- 33”
- Depth:
- 18.5”
- Air Throw:
- 150’
- Weight:
- 93 lbs
- Package Size:
- Each
