The Patterson PB14B High Velocity Fan is a rugged, purpose-built cooling solution designed for factory, warehouse, and workstation environments. This 14-inch, direct-drive fan delivers potent airflow to help improve air circulation, support condensation control, and create a more comfortable workspace for extended shifts. Its compact footprint and durability-focused construction make it suitable for use in aisles, pick modules, workstations, and shipping or staging zones where reliable, high-velocity air movement is needed.
Construction combines a high-impact polypropylene housing with heavy-gauge steel components and a three-blade, 14-inch propeller. The fan employs patented Venturi-designed barrels and side air intakes to project and entrain air effectively across a broad area. It uses maintenance-free, direct-drive motors with sealed bearings for longevity, with options for multiple voltages (115V–460V) and variable speeds on select sizes (14
Features:
- 14" diameter, 3-blade propeller
- High-impact polypropylene housing with heavy-gauge steel construction
- Patented venturi-designed barrels
- Side air intakes for efficient cooling
- Maintenance-free direct-drive motor with sealed bearings
- Multiple voltages: 115V–460V
- Eight mounting options and optional oscillator kits
- OSHA-compliant steel finger guards
- 12' power cord (115V only)
- 2-year warranty
- Propeller:
- 14” Diameter, 3-Blade Galvalum, 37°
- Fan Inlet/Outlet:
- High-Impact Polypropylene
- Finger Guards:
- OSHA-Compliant
- Power Cord (115V Only):
- 12’ Length (Switch Optional)
- RPM:
- 1725
- Decibels:
- 63.1 @ 20’ - 73.1 @ 3’
- Coverage:
- 1800 ft²
- Warranty:
- 2 Years
- CFM:
- 2600
- HP:
- 1/4
- Width:
- 20”
- Depth:
- 16”
- Air Throw:
- 60’
- Weight:
- 35 lbs
- Package Size:
- Each
