The Patterson CS34B is a high-velocity, industrial floor fan designed to move large volumes of air in demanding manufacturing and warehouse environments. With a 34-inch three-blade propeller and a robust construction, this unit delivers elevated air movement to help improve ventilation, reduce heat buildup, and support overall worker comfort in expansive spaces such as aisles, pick modules, and staging areas. The design emphasizes durability and adaptability, making it suitable for applications where long runtimes and dependable performance are essential.
Key features include a patented Venturi-designed barrel and side air inlets that work together to project and entrain air across a substantial throwing distance. The unit employs a maintenance-free, direct-drive motor with sealed bearings housed in a heavy-gauge steel frame and high-impact polypropylene (HIPP) housing. It is available in multiple voltages (115V–460V) and can be configured with options such as an oscillator kit and various mounting configurations to fit unique facility layouts. An OSHA-compliant steel finger guard is included for added safety, while a 12-foot power cord is provided with 115V versions.
Practical considerations for installation and operation include selecting the appropriate voltage and mounting method to best cover targeted areas, understanding that the unit is designed for continuous use in industrial settings, and acknowledging the unit’s substantial air output, which can influence ceiling clearances and ducting plans. The CS34B’s performance is aligned with tasks that require rapid air displacement across large spaces, making it a viable solution for improving air circulation and helping manage environmental conditions in busy work zones. Product availability, packaging, and warranty details are provided by The Safety Source.
Features:
- 34" diameter, 3-blade galvalum propeller
- High-impact polypropylene housing with heavy-gauge steel construction
- Venturi-designed barrels for efficient airflow
- Direct-drive, maintenance-free motors with sealed bearings
- Multiple voltages: 115V–460V
- Eight mounting options
- OSHA-compliant steel finger guards
- 12' power cord (115V only)
- 2-year warranty
- Propeller:
- 34” Diameter, 3-Blade Galvalum, 15°
- Fan Inlet/Outlet:
- 14-Gauge Spun Steel
- Finger Guards:
- OSHA-Compliant
- Power Cord:
- N/A
- RPM:
- 1200
- Decibels:
- 88 @ 20’
- Coverage:
- 17,000 ft²
- Warranty:
- 2 Years
- CFM:
- 17,000
- HP:
- 3
- Width:
- 43.5”
- Depth:
- 25.5”
- Air Throw:
- 230’
- Weight:
- 215 lbs
- Package Size:
- Each
