PATCS22B Patterson high-velocity fan designed for demanding factory and warehouse environments. This 22-inch model delivers robust air movement to improve circulation, aid in condensation control, and help maintain a cooler, more productive workspace. The unit features a Venturi-designed barrel and optimized side inlets to project and entrain air across long distances, making it well-suited for use in aisles, pick modules, workstations, and shipping or staging zones. The fan is built with a high-impact polypropylene housing paired with heavy-gauge steel, and it uses a maintenance-free, direct-drive motor with long-lasting sealed bearings (totally enclosed). A 21-inch three-blade Galvalum propeller provides strong performance, with an RPM of 1725 and a documented air throw of up to 100 feet, enabling effective air movement across large areas. This model supports multiple voltages (115V–460V) and offers options such as adjustable speed motors (14
Features:
- 22" (21" propeller) three‑blade design for high airflow
- High‑impact polypropylene and steel housing for durability
- Pertinent venturi-designed barrels for optimized air flow
- Maintenance-free direct-drive motor with sealed bearings
- Multiple voltages: 115V–460V; 12 ft cord included (115V only)
- Eight mounting options with chain suspension compatibility
- OSHA-compliant finger guards and optional oscillator kits
- Coverage up to 3600 ft² and air throw up to 100 ft
- 2-year warranty
- Propeller:
- 21” Diameter, 3-Blade Galvalum, 19°
- Fan Inlet/Outlet:
- High-Impact Polypropylene
- Finger Guards:
- OSHA-Compliant
- Power Cord (115V Only):
- 12’ Length (Switch Optional)
- RPM:
- 1725
- Decibels:
- 66.5 @ 20’ - 77.6 @ 3’
- Coverage:
- 3600 ft²
- Warranty:
- 2 Years
- CFM:
- 5570
- HP:
- 1/2
- Width:
- 29”
- Depth:
- 16”
- Air Throw:
- 100’
- Weight:
- 49 lbs
- Package Size:
- Each
