The Litetronics WPC100 is a versatile 2-in-1 wall pack designed for exterior lighting applications, offering either traditional or full cut-off operation in a single unit. This 100-watt fixture is capable of operating on a 120–277V supply, delivering multiple lumen outputs (8,400; 10,800; or 13,500) with a color-temperature range selectable among 3000K, 4000K, and 5000K to suit different site requirements. Aimed at efficient site-wide lighting control, the WPC100 includes a photocell and a pluggable sensor socket, and supports optional sensors for PIR, microwave, or LiteSmart technology to facilitate energy savings and group-level management as needed by local codes or regulations.
Construction and installation focus on ease of mounting and wiring. The unit features a matte powder coat finish and a 93° beam angle to provide broad, effective illumination while staying within typical exterior mounting considerations. With a rated average life of up to 50,000 hours, a power factor around .95, and a lumen-per-watt ratio of about 135, this fixture offers a balance of performance and efficiency for outdoor environments. The design accommodates damp locations and is compatible with the LiteSmart app ecosystem when configured with the appropriate sensors, enabling remote or centralized control where supported.
Practical installation notes suggest swing-open access to simplify electrical connections and mounting on exterior walls, with an EVA cotton pad included for wall-mount installation. This product is positioned for applications such as building perimeters, walkways, and entryways that require reliable, controllable illumination with options for sensor-driven automation in compliant lighting schemes. Specific electrical ratings, mounting details, and sensor compatibility should be confirmed in the project design phase to ensure compatibility with existing controls and local requirements.
Features:
- 2-In-1 traditional or full cut-off wall pack design
- Supports 120-277V input
- Field selectable wattages and CCT (3000K, 4000K, 5000K)
- Photocell and pluggable sensor socket
- LiteSmart app compatibility
- Beam angle 93°
- Watts up to 100W, up to 13,500 lumens
- Brand:
- LED 2-In-1 Traditional or Full Cut Off Wall Pack
- Watts:
- 100
- Voltage:
- 120-277V
- Average Rated Life:
- 50,000 hrs.
- Luminaire Lumens:
- 8,400 | 10,800 | 13,500
- CRI:
- 80
- Color Temp:
- 3000K | 4000K | 5000K
- Finish:
- Matte Powder Coat
- Operating Temp:
- -40F to 113°F (-40 Degrees C to 45 Degrees C)
- Power Factor:
- ?.95
- Warranty:
- 5 years
- Beam Angle:
- 93°
- THD:
- ? 20%
- Lumens/Watt:
- 135
- Suitable for Damp Locations:
- Yes
- Package Size:
- Each
