The Alvarado MSGXPX48-GL is a full-height pedestrian security gate designed for controlled access in industrial and facility environments. It features a 48-inch opening and a galvanized steel construction, delivering a robust barrier that can be integrated with full-height turnstiles to accommodate accessibility passages or material deliveries. The gate ships pre-framed and fully assembled, helping simplify installation in secure or high-traffic areas.
Construction and notable features include a welded frame and gate assembly with metal infill bars and infill mesh, providing a strong yet visible barrier. The operating package includes hydraulically dampened closing for controlled latching, a magnetic lock on the entry side combined with a pull handle, and a microswitch push bar on the exit side to support basic access control workflows. The unit is finished with hot-dipped galvanization, which offers corrosion resistance suitable for outdoor or harsh environments where gate integrity matters over time.
Practically, the MSGXPX48-GL is positioned for applications requiring a wide pedestrian passage that can still restrict unauthorized entry, such as between work zones, warehouse borders, or entry points adjoining turnstile systems. When configuring for a site, verify that the 53.2-inch width and 91-inch height fit the intended opening, and account for the 12-inch depth in your surrounding framing or mounting. Maintenance considerations center on ensuring the hydraulic closer operates smoothly and that the galvanizing coating remains intact to preserve corrosion resistance over time.
Features:
- Hydraulically Dampened Closing
- Single Direction Operation
- Magnetic Lock (Fail Safe) with Entry-Side Pull Handle
- Microswitch Push Bar on Exit Side
- Metal Infill Bars with Infill Mesh
- Hot Dipped Galvanized Finish
- 48" Opening
- Width:
- 53.2
- Height:
- 91.0
- Color:
- Silver
- Package Size:
- Each
- Depth:
- 12.0
- Material:
- Galvanized Steel
