The Zing Green ZIN7273 1- Piece Steel Small Ball Valve Lockout is designed to secure most common ball valves in the OFF position, helping to prevent unintended valve operation during maintenance or servicing. This compact lockout is constructed from steel, providing a durable, compact solution for smaller valve handles. It features eight precise positioning holes, enabling flexible padlock alignment to accommodate different lock configurations and to reinforce lockout integrity. The maximum handle thickness is 9/32 inch and the maximum handle width is 1-29/64 inch, which define the range of valve sizes this device can accommodate. A padlock with a shackle up to 9/32 inch in diameter can be integrated through the corresponding holes, supporting a single- or multi-lockout setup as needed for workforce safety protocols.
Use considerations for this lockout center on ensuring the device fits the target valve and that the lockout configuration aligns with your facility’s safety procedures. The eight-hole design allows operators to position padlocks accurately, providing a reliable lockout point for routine maintenance tasks. Given its steel construction and compact form, it is suitable for smaller ball valves commonly found in facility maintenance applications. Packaging notes indicate the item is sold as an individual unit, enabling straightforward deployment across multiple workstations as part of a broader lockout/tagout program.
Features:
- Locks most ball valves in OFF position
- Max handle thickness: 9/32"
- Max handle width: 1-29/64"
- 8 positioning holes for secure alignment
- Padlocks with up to 9/32" shackle supported
- Material: steel
- One-piece lockout design
- Material:
- steel
- Max handle thickness:
- 9/32?
- Max handle width:
- 1-29/64?
- Padlock holes:
- 8 positions
- Max padlock shackle:
- 9/32?
- Package Size:
- Each
