Draeger 8103631 Gas Detector Tube, Nitrogen Dioxide 0.1/a, 10/Box

Draeger 8103631 Gas Detector Tube is a disposable glass tube designed for qualitative and quantitative measurement of nitrogen dioxide in ambient air when used with a Draeger tube pump. This specific tube is configured for an NO2 range around 0.1 per a in the 0.1/a presentation, and is packaged as a box containing 10 individual tubes for convenient classically based gas analysis. The device relies on colorimetric reaction within a glass tube to indicate concentration after a defined sampling period, making it suitable for field checks and routine workplace monitoring where quick, on-site results are preferred.

Each tube is built from glass and features a break-off tip to enable easy sampling and transfer of the sample into the detection reagents. The product supports measurement at multiple ranges, including 0.1–5 ppm and 5–30 ppm, with typical completion times around 75 seconds or 30 seconds depending on the range and method used. This documentation-based description reflects the standard Dräger-tube approach to gas analysis, where the user operates with a Draeger pump to pull a known air volume through the tube to produce a color change proportional to the NO2 concentration.

Because this is a tube-based detector, it is important to verify the exact range, measurement time, and packaging when selecting replacement tubes for ongoing monitoring. The package size is listed as a box, with 10 tubes per box, which supports repeat measurements across shifts or multiple sampling points without frequent reorders. Maintenance involves ensuring the tube integrity, proper pump use, and adherence to any local workflow or regulatory requirements for gas monitoring.

Features:

• Gas Detected: Nitrogen Dioxide 0.1/a
• Measurement Ranges: 0.1 - 5 ppm and 5 - 30 ppm
• Measurement Time Options: 75 Sec and 30 Sec
• Tube Material: Glass
• Break-Off Tip: Yes
• Package Size: Box
• Box Quantity: 10 Tubes per Box
