Name: Litetronics LHB112UR240DLP 112W Linear High Bay 17,920 Lumens 4000K 120-277V
Brand: Litetronics
SKU: LHB112UR240DLP
Price: 105.41 USD
Availability: InStock

Litetronics LHB112UR240DLP 112W Linear High Bay 17,920 Lumens 4000K 120-277V

Litetronics

SKU:

LHB112UR240DLP

$105.41

/ Each

Weight:

10.00 LBS

The Litetronics LHB112UR240DLP is a high-performance LED linear high bay designed for demanding spaces such as warehouses, industrial facilities, sports venues, manufacturing floors, and retail centers. It delivers a robust 112-watt package with an impressive 17,920 lumens and a nominal 160 lumens per watt, providing bright, pervasive illumination suitable for high-ceiling environments where uniform light is essential. The fixture is engineered for 120–277V operation (with variants available for other voltage ranges), making it flexible for a wide range of installations and power infrastructures. Its construction includes extruded aluminum housing and a polycarbonate frosted lens, contributing to durability and light quality while withstanding typical industrial settings.

Key features support efficient, low-maintenance operation. The unit ships ready for ceiling mounting and is compatible with dimming via 0–10V control, enabling reduced light levels when full output isn’t required. With RoHS compliance and DLC listings (DLC, DLC Premium) and UL listing, this fixture is positioned for energy-efficiency programs and certified performance in professional settings. The 4000K color temperature provides a neutral, true-white light that is widely preferred for work environments, helping to maintain visibility and color discrimination without excessive glare. The fixture is designed for suspended installation but can be mounted in pendant or surface configurations as needed, and it includes mounting considerations suitable for a variety of industrial layouts.

When planning installation, note the product’s damp location rating and its non-wet specification, which guides suitability for indoor spaces that may experience humidity without direct water exposure. This LHB112UR240DLP model is delivered as a single unit per package, and it’s compatible with existing electrical and mounting plans that support linear high bay form factors. In practice, the combination of high lumen output, efficiency, and flexible mounting makes it a practical choice for upgrading from traditional fluorescent high bays, reducing maintenance while delivering consistent lighting performance across large areas.

Features:

112 W linear high bay luminaire
17920 lumens for bright indoor spaces
4000K color temperature for neutral white light
0-10V dimming for lighting control
UL Listed, DLC Listed and DLC Premium Listed
RoHS compliant
Ceiling mount installation

UL Listed products have been independently evaluated and certified to meet applicable safety standards established by UL Solutions. This certification indicates that the product has undergone testing for potential electrical, fire, and other safety hazards relevant to its intended use. Commonly found on LED lighting fixtures, electrical equipment, and commercial products, UL Listing helps demonstrate compliance with recognized product safety requirements and includes ongoing certification oversight.

Color Temperature	Description
2700K – Warm White	Soft, warm white light with a yellowish tone, ideal for comfortable and inviting environments.
3000K – Warm White	Warm white illumination suitable for offices, reception areas, and commercial interiors.
3500K – Neutral White	Balanced white light offering a comfortable appearance for offices, classrooms, and retail spaces.
4000K – Cool White	Clean, neutral white light commonly used in warehouses, offices, and industrial facilities.
4500K – Cool White	Crisp white illumination suitable for workshops, commercial buildings, and general task lighting.
5000K – Daylight	Bright-looking, daylight-like white light commonly used in manufacturing, warehouses, and work areas.
5700K – Daylight White	Cool, daylight-like illumination suitable for industrial facilities and outdoor lighting.
6000K – Cool Daylight	Cool white light with a slight bluish tone, suitable for industrial and commercial applications.
6500K – Daylight	Very cool, daylight-like white light often used in inspection areas and specialized workspaces.
Selectable CCT	Allows users to select between preset color temperatures to accommodate different lighting preferences.
Tunable White	Provides adjustable color temperature across a supported range for flexible lighting applications.

Note: Capacity includes the worker, clothing, tools, and equipment. OSHA compliance depends on the complete fall protection system and its intended use, not the weight rating alone.

CRI Rating	Description
CRI 70	Provides basic color rendering suitable for warehouses, storage areas, and general industrial lighting where precise color identification is not critical.
CRI 80	Delivers good color accuracy for offices, warehouses, manufacturing facilities, and everyday commercial lighting applications.
CRI 82	Offers good color rendering for commercial and industrial environments, helping maintain natural-looking colors and clear visibility.
CRI 85	Provides enhanced color accuracy for retail spaces, offices, workshops, and applications where color distinction is important.
CRI 90	Delivers excellent color rendering for applications requiring accurate color identification, including inspection areas, retail displays, and detailed workspaces.
CRI 95	Offers exceptional color accuracy for specialized applications such as color inspection, photography, and precision manufacturing.
CRI 98	Provides near-reference color rendering accuracy, ideal for demanding applications requiring highly accurate color reproduction and visual evaluation.
CRI 100	Represents the maximum CRI score, indicating color rendering equivalent to the applicable reference illuminant under the CRI measurement system.

Package Size:: Each
Package Includes:: 1/Each
Wattage:: 112
Lumens:: 17920 Lumens
Lumens Per Watt:: 160
Color Temp:: 4000K
CRI:: 80
Dimmable:: 0-10V Dimming
UL Listed:: Yes
DLC Listed:: Yes
DLC Premium Listed:: Yes
Wet Location:: No
Damp Location:: Yes
Hazardous Location:: No
Certifications:: RoHS
Color Finish:: White
Mounting Type:: Ceiling Mount

What are the key technical specifications of the LHB112UR240DLP LED Linear High Bay?

The fixture is 112W with 17,920 lumens, 160 lumens per watt, color temperature 4000K, CRI 80, and is dimmable 0-10V. It is UL listed, DLC Listed, and DLC Premium Listed, with a white finish and ceiling mount.

What mounting and installation options are available for this fixture?

Ceiling-mounted LED fixture with frosted polycarbonate lens, extruded aluminum housing, and included suspension cables.

In what locations or applications is the LHB112UR240DLP suited for?

It is intended for warehouse and storage, industrial facilities, sports facilities and gyms, manufacturing facilities, and retail centers.

Does this LED High Bay support any smart features like motion sensing or daylight harvesting?

The product description mentions a built-in PIR sensor for motion sensing and daylight harvesting as an option, with adjustable settings accessible via the Sensor Remote Control.
