The Green Creative 40T8/8F/850/DEB/R17d is an 8-foot LED T8 replacement lamp designed to substitute high-energy fluorescent tubes in commercial and industrial settings. With a 40-watt operating load and a color temperature of 5000K, it provides bright, daylight-like illumination while delivering up to 5,500 lumens and an efficacy around 137.5 lm/W. The lamp uses a UL Type B - Double-Ended Bypass (DEB) wiring approach and an R17d recessed double-contact base, enabling straightforward installation into compatible fixtures without ballast modification. It is rated for enclosed fixtures and is suitable for indoor applications including food-processing environments, warehouses, manufacturing facilities, cold storage, and utility spaces, with operation across a wide voltage range of 120–277V at 50/60 Hz. The unit is designed for damp locations and a wide operating temperature span, from -4 to 113 degrees, supporting diverse industrial settings while maintaining performance.
Constructed to replace traditional F96T8 and F96T12 fluorescent tubes, this lamp emphasizes energy efficiency and reduced maintenance compared to legacy fluorescent systems. Its 8-foot form factor and 94 inch length align with standard long-tube layouts, aiding in retrofits where fixture length and mounting alignments are critical. The product ships as a pack with ten tubes per package, and it carries a 5-year limited warranty, reflecting compatibility with Green Creative’s long-term replacement strategy. The combination of high color rendering (CRI 82) and 5000K daylight tone supports tasks requiring good visual acuity and consistent color perception in work environments, while a low power factor and distortion are managed within typical industry specs. This lamp is cULus classified and NSF-listed for food zones, helping address safety and sanitation considerations in appropriate settings.
Features:
- 8 Foot T8 LED Tube with R17d Recessed Double-Contact Base
- 5000K Daylight Color, 5,500 Lumens
- UL Type B - Double-Ended Bypass (DEB) Wiring
- Enclosed Fixture Rated, Indoor/Damp Locations
- Wide Input Voltage 120–277V; PF 0.9, THD <20%
- 50000 Hours L70 Life
- 5-Year Limited Warranty
- Package Size:
- Pack
- Package Includes:
- 10/Each
- Model Number:
- 40T8/8F/850/DEB/R17d
- Lamp Length / Type:
- 8 Foot / T8
- Base Type:
- R17d (Recessed Double Contact)
- Equivalent Replacement:
- F96T8 / F96T12 Fluorescent
- Wiring Type:
- UL Type B - Double-Ended Bypass (DEB)
- Input Voltage:
- 120-277V, 50/60Hz
- Wattage:
- 5,500 lm
- Efficacy:
- Efficacy
- Color Temperature (CCT):
- 5000K (Daylight)
- Color Rendering Index (CRI):
- 82
- Beam Angle:
- 160° (310° Light Emitting Area)
- Power Factor / THD:
- 0.9 / <20%
- Fixture Rating:
- Enclosed Fixture Rated
- Environment:
- Indoor / Damp Locations
- Operating Temperature:
- -4 degrees to 113 degrees
- Dimensions (MOL x Dia.):
- 94 x 1-1/16
- Weight:
- 0.88 lbs
- Lifetime (L70):
- 50,000 Hours
- Certifications:
- cULus Classified, FCC, NSF (Food Zone Non-Contact, Splash, Non-Food)
- Warranty:
- 5-Year Limited Standard
