The Litetronics VLFT2 is a versatile LED panel designed to replace traditional 2' x 2' fixtures with adjustable light settings, giving installers and facility managers flexibility in a single product. It offers selectable wattage and color temperature, with options for 18, 27, or 36 watts and 3500K, 4000K, or 5000K, enabling quick adaptation to different spaces or tasks without stocking multiple SKUs. The luminaire is built to deliver broad, even illumination and a practical color render, making it suitable for general ambient lighting in commercial and industrial settings.
Construction and key characteristics include a compact 2' x 2' form factor, a polycarbonate frosted diffuser for soft, diffused light, and an impact-resistant design. The unit supports 0-10V dimming and operates on 120-277V with a high power factor and low total harmonic distortion, contributing to energy efficiency and predictable performance. With a rated life of up to 50,000 hours, the fixture is intended for long service intervals and reduced maintenance. The product also supports integration with emergency battery backup systems and carries damp-location suitability, aligning with various indoor installation environments.
Practical considerations for selection include its listed beam angle of 110 degrees and UGR range typical of a 2' x 2' panel, which informs glare control in workspaces. The fixture is RoHS compliant and designed for IP80 protection, providing basic dust and moisture resistance appropriate for indoor use. Compliance and listing status noted as ETL pending and DLC rating for the 2' x 2' size is pending, so customers should verify final listings prior to procurement. The VLFT2’s adjustable lumen and wattage options help control energy use and lighting levels, particularly in spaces where zoning or occupancy-based lighting is desired.
Features:
- Selectable wattage: 18/27/36W for 2' x 2' frame
- Selectable CCT: 3500K, 4000K, 5000K
- 0-10V dimming
- 50,000-hour rated life
- 5-year warranty
- Compatible with Emergency Battery Backup
- UGR 28-30 (2' x 2' product)
- Average rated life:
- 50,000 hours (@L70)
- Warranty:
- 5 years
- Operating temp:
- 32°F - 104°F
- Surge protection:
- 2.5KV
- Input voltage:
- 120-277V
- Input frequency:
- 50/60Hz
- Power factor:
- ≥0.95
- THD:
- ≤20
- CRI:
- 80
- Beam angle:
- 110°
- Diffuser type:
- Polycarbonate frosted
- Dimming:
- 0-10VDC ANSI C137.x compliant
- Minimum dimming:
- 0% of rated lumen LED drive current
- Location rating:
- Damp
- ETL listed:
- Pending
- RoHS compliant:
- Yes
- DLC rating:
- 2’x2’ Pending
- IC rated:
- Yes
- IP rating:
- 80
- LPW:
- 125
- Package Size:
- Each
