The ILP Endeavour 2.0 EDV4-24L-U-50 is a high bay lighting fixture designed for demanding industrial and commercial environments. Its powerful output and wide operating temperature range make it suitable for spaces that require bright, reliable illumination across large areas. The luminaire delivers 159 watts and 25,447 lumens with a typical efficiency of 160 lumens per watt, supporting clear visibility and task performance in warehouses, manufacturing floors, and distribution centers. With a color temperature of 5000K, the light is tuned for crisp, daylight-like illumination that helps reduce eye strain during long shifts.
Construction features contribute to durability and ease of installation. The unit uses an aluminum body with steel channels for rigidity, and curved polycarbonate end caps. It supports both wide and narrow distributions and includes V-clips for dual-point hanging, offering flexible mounting options. A tool-less hinged driver access design simplifies maintenance, while the uplight option enhances overall room illumination by bouncing light off ceilings and upper walls when needed. The fixture is ETL Listed for Damp Location use and is compatible with DesignLights Consortium Premium Qualified status, underscoring its performance and efficiency credentials.
Performance and applicability are reinforced by practical considerations: the EDV4-24L-U-50 accepts a 0-10V dimming driver for 100% to 10% dimming, enabling lighting control strategies to save energy and extend lamp life. It is rated for a wide ambient temperature range (standard -40°F to 131°F, with an optional 149°F max high ambient temperature), ensuring consistent operation in varied environments. The fixture is designed for easy integration into existing lighting systems and is backed by a 5-year warranty with a 10-year optional extension, reflecting a balance of value and reliability for industrial facilities.
Features:
- Aluminum body with steel channel for rigidity
- Tool-less hinged driver access
- Wide & Narrow distributions
- Uplight options to enhance full-room illumination
- 0-10V dimmable driver
- ETL Listed for Damp Location
- DLC Premium Qualified
- Input Voltage:
- 120-277V
- Color Temp:
- 5000K
- Watt:
- 159
- Lumens:
- 25447
- Lumen Per Watt:
- 160
- CRI:
- >80
- Finish:
- White
- ETL Listed:
- Yes
- DLC:
- Premium
- Operating Temperature Range:
- -40F to 131F
- IP Rating:
- IP5X
- Average Rated Life:
- 100,000 hrs
- Warranty:
- 5 Years
- Package Size:
- Each
