The Patterson V-Series HVLS ceiling fan brings large-diameter airflow to industrial spaces without clutter or cords on the floor. At 8 feet in diameter, this model is designed to move substantial volumes of air quietly, supporting comfort and productivity while reducing ground moisture that can contribute to slick floors. Its direct-drive configuration eliminates gears, reducing maintenance needs and weight, which simplifies installation and support in ceiling-mounted applications. The V8A-220 provides steady, adjustable air movement with forward, reverse, and variable-speed options to tailor performance to season and occupancy needs, helping to even temperature distribution across large areas.
Construction and features are focused on efficiency and reliability in demanding environments. The design includes wingtip optimization to minimize airflow loss at blade tips and blades contoured for maximum air movement, maximizing the effective reach of the fan. The system is designed for indoor or outdoor covered spaces, offering IP66-rated VFD and IP54-rated motor protection for compatibility with diverse installation conditions. A multi-tier safety system supports installation and operation in rough industrial settings, helping ensure dependable performance in a variety of work environments.
This model is specified for substantial coverage, suitable for open facilities with a large reach—up to an 6,850 square-foot effective area and a 60-foot industrial spacing guideline. It weighs approximately 77 pounds, with a 0.5 HP (0.3 kW) motor running on 220V single-phase service. When planning installation, consider package sizing (each unit) and the required mounting clearances to achieve the intended air movement and energy efficiency benefits across shifts and seasons.
Features:
- Direct Drive: zero gears means zero maintenance
- Wingtips minimize airflow loss and direct air downward
- Contoured blades for maximum air movement
- Low weight due to gearbox-free design
- Sound under 42 decibels for quiet operation
- Forward, Reverse and Variable Speed
- IP66 VFD and IP54 motor ratings for indoor/outdoor covered spaces
- Multi-tier safety system for industrial environments
- Size:
- 8 ft Diameter
- Number of Blades:
- 5
- Industrial Spacing:
- 60 ft (18.3 m)
- Max Effective Area:
- 6850 ft² (636 m²)
- Max RPM:
- 120 RPM
- Hanging Weight:
- 77 lbs (30 kg)
- Motor:
- .5 HP (0.3 kW)
- Voltage:
- 220V Single-Phase
- Package Size:
- Each
