The Patterson RM30A is a high-velocity, industrial ceiling- or rack-mounted fan designed to move large volumes of air in warehouse and factory spaces. Built around a 30-inch two-blade propeller, its high-velocity airflow supports aisle ventilation, improved circulation around workstations, and condensate control in staging areas. The unit uses a Venturi-designed barrel and side air inlets to project and entrain air across substantial distances, helping to create a more comfortable and safer working environment while potentially reducing cooling loads in large spaces.
Constructed with a high-impact polypropylene housing and a heavy-gauge steel frame, the RM30A combines durable materials with maintenance-free, direct-drive motors that are maintenance-free and sealed. The design includes OSHA-compliant steel finger guards and multiple mounting options, including eight distinct configurations, to support flexible installation in facilities with varying layouts. The motor options cover multiple voltages up to 460V and some configurations offer variable-speed capability for precise airflow control. A 12-foot cord is specified for the 115V version, contributing to ease of placement without immediate power access requirements.
This model is suited for applications such as large-dimension air movement across aisles, pick modules, and shipping or staging zones, where strong airflow is needed to refresh air, assist in cooling, and reduce stagnation. When selecting a unit, consider room size, mounting height, and electrical availability, as well as the potential need for optional oscillator kits to modulate air throw. The RM30A ships as a single unit and carries a two-year warranty, providing a defined support window for installation and service needs.
Features:
- 30" diameter, 2-blade Galvalum propeller
- High-impact polypropylene housing with heavy-gauge steel construction
- Patented Venturi-designed barrels
- Side air intakes and OSHA-compliant finger guards
- Maintenance-free, direct-drive motor with sealed bearings
- Multiple voltages: 115V–460V; 12' power cord (115V)
- Optional oscillator kits and eight mounting options
- 2-year warranty
- Propeller:
- 30” Diameter, 2-Blade Galvalum, 15°
- Fan Inlet/Outlet:
- High-Impact Polypropylene
- Finger Guards:
- OSHA-Compliant
- Power Cord (115V Only):
- 12’ Length (Switch Optional)
- RPM:
- 1800 (standard)/ 1200 (optional)
- Decibels:
- 82.2 @ 20’ - 85.5 @ 3’ (1800)
- Coverage:
- 12,000 ft²
- Warranty:
- 2 Years
- CFM:
- 12,000
- HP:
- 1
- Width:
- 37”
- Depth:
- 22”
- Air Throw:
- 200’
- Weight:
- 99 lbs
- Package Size:
- Each
