The Patterson PS14B High Velocity Fan is a portable, high-performance ventilation solution designed for demanding industrial environments such as warehouses and production areas. This 14-inch model delivers robust air movement to improve circulation, assist with condensation control, and help maintain a comfortable, safer workspace around aisles, workstations, and staging zones. Its compact, portable form supports flexible deployment wherever cooling or ventilation is needed, without locking you into a fixed setup.
Constructed for durability, the PS14B uses a high-impact polypropylene housing paired with heavy-gauge steel, and features Patterson’s patented Venturi-designed barrels with side air intakes to project and entrain air efficiently over a distance. The unit is available with direct-drive, maintenance-free motors that include long-lasting sealed bearings and a totally enclosed design. This configuration supports reliable operation across multiple voltages (115V–460V) and is compatible with several mounting options, including optional oscillation kits, to tailor air flow to specific spaces. The blade assembly is a 3-blade galvalume propeller, balanced to deliver air effectively to an area up to 1,800 square feet, with a measured air throw of up to 60 feet.
In terms of practical use, the PS14B is suited for environments where steady air movement helps reduce heat buildup, improve air quality, and promote worker comfort. Because it is offered with options such as variable-speed motors for precise control and OSHA-compliant finger guards for safety, it supports customizable configurations to fit varied facility layouts. The unit ships with a 12-foot cord for 115V operation, and a two-year warranty provides a tangible assurance of durability for ongoing facility needs.
Features:
- 14" diameter, 3-blade propeller with 2600 CFM
- Direct-drive, maintenance-free motor with sealed bearings
- Multiple voltages: 115V–460V
- OSHA-compliant steel finger guards
- Venturi-designed barrels for efficient airflow
- High-impact polypropylene housing with heavy-gauge steel construction
- Eight mounting options and optional oscillator kits
- Propeller:
- 14” Diameter, 3-Blade Galvalum, 37°
- Fan Inlet/Outlet:
- High-Impact Polypropylene
- Finger Guards:
- OSHA-Compliant
- Power Cord (115V Only):
- 12’ Length (Switch Optional)
- RPM:
- 1725
- Decibels:
- 63.1 @ 20’ - 73.1 @ 3’
- Coverage:
- 1800 ft²
- Warranty:
- 2 Years
- CFM:
- 2600
- HP:
- 1/4
- Width:
- 20”
- Depth:
- 16”
- Air Throw:
- 60’
- Weight:
- 35 lbs
- Package Size:
- Each
