The Patterson Fan BC26B is a high-velocity industrial fan designed to move large volumes of air efficiently in factory, warehouse, and logistics spaces. This 26-inch, three-blade model delivers substantial airflow to improve circulation, help ventilate aisles, workstations, and staging areas, and support occupant comfort and condensation control in wide spaces. Its rugged construction combines a high-impact polypropylene housing with heavy-gauge steel components, and it uses a patented Venturi-designed barrel to project and entrain air over long distances. The unit is available with a direct-drive, maintenance-free motor that features sealed bearings and a totally enclosed design, helping reduce downtime for routine servicing.
The BC26B supports a range of installation and operation options to fit varied facility layouts. It comes with OSHA-compliant steel finger guards for added protection and a choice of mounting arrangements to position the fan where airflow is most effective. Optional features include oscillator kits and multiple voltages (115V–460V), as well as an available variable-speed motor option for 14"–22" models, enabling tailored airflow without sacrificing efficiency. A 12 ft power cord is included for 115V installations, and the fan is intended for heavy-duty use in environments where long air throws and broad coverage are required, with an air throw reaching up to 150 feet and a stated coverage of up to 6100 square feet.
In practice, this fan supports operations that need robust air movement to improve ventilation, control humidity, and create a more comfortable work environment across large floor areas. When selecting power and mounting configurations, verify voltage compatibility and mounting options to ensure the unit integrates with your facility’s electrical and structural setup. The product ships as a single unit with a general compatibility footprint suitable for industrial spaces that require high-velocity air delivery and reliable, maintenance-free operation.
Features:
- 26" diameter, 3-blade Galvalum propeller
- High-impact polypropylene housing with heavy-gauge steel frame
- Venturi-designed barrels for efficient air flow
- Maintenance-free, direct-drive motor with sealed bearings
- Multi-voltage operation: 115V–460V
- OSHA-compliant steel finger guards
- 12 ft cord (115V only) and multiple mounting options
- Propeller:
- 26” Diameter, 3-Blade Galvalum, 18°
- Fan Inlet/Outlet:
- High-Impact Polypropylene
- Finger Guards:
- OSHA-Compliant
- Power Cord (115V Only):
- 12’ Length (Switch Optional)
- RPM:
- 1800 (standard)/ 1200 (optional)
- Decibels:
- 80.8 @ 20’ - 85.2 @ 3’ (1800)/ 75.7 @ 20' - 81.3 @ 3' (1200)
- Coverage:
- 6100 ft²
- Warranty:
- 2 Years
- CFM:
- 7650
- HP:
- 1
- Width:
- 33”
- Depth:
- 18.5”
- Air Throw:
- 150’
- Weight:
- 93 lbs
- Package Size:
- Each
