CGW 37747 is a 14 inch diameter surface grinding wheel designed for heavy stock removal with a precise finish. Built with mono-crystalline aluminum oxide grain, it blends versatility with solid performance across a wide range of materials and applications. The wheel’s Type 1 configuration and 46 grit size (with a 32A mono-crystalline aluminum oxide composition) provide a balance between aggressive material removal and the ability to achieve defined dimensions, making it suitable for mid- to heavy-stock grinding tasks. Its hardness grade I supports stable cutting action under typical shop conditions and enables predictable wear patterns that help maintain consistent workpiece dimensions over time.
This wheel features a 1-1/2 inch thick profile on a 14 inch diameter with a 5 inch arbor/shank, designed to fit compatible grinders that accept a 5 inch arbor. The rated operating speed is 1910 RPM, which corresponds to typical safe operating ranges for this size wheel when used with proper guards and machine enclosures. The packaging indicates a two-piece box quantity per order, with each wheel identified by the CGW part number CGW37747, ensuring traceability for inventory and reordering. When selecting a wheel for a given job, verify material compatibility, required stock removal rate, and the finish target to determine if a 46-grit, 32A mono-crystalline aluminum oxide wheel is appropriate for achieving the desired surface finish.
In practical use, users should confirm machine compatibility with the wheel size and arbor specification, maintain correct wheel guards, and ensure appropriate wheel dressers or truing methods are available to sustain cutting efficiency. Adherence to standard safety practices for grinding operations remains essential, including proper PPE, guarding, and workpiece securing. Since exact specifications such as the diameter, thickness, grit, hardness, and RPM are provided, buyers can precisely match this wheel to their equipment and process requirements.
Features:
- Surface grinding wheel for heavy stock removal and precise finish
- 32A mono-crystalline aluminum oxide grain for versatility
- Medium to heavy stock removal capability
- 14" diameter, 1-1/2" thickness, 5" arbor
- Grit 46, Grade I, RPM 1910
- Package Size: Each, Box Quantity: 2
- Grain:
- 32A - Mono-Crystalline Aluminum Oxide
- Dia:
- 14
- Thickness:
- 1-1/2
- Arbor/Shank Size:
- 5
- Type:
- 1
- Grit:
- 46
- Grade/Hardness:
- I
- RPM:
- 1910
- Package Size:
- Each
- Box Quantity:
- 2
