Zing Green 7316 Miniature Circuit Breaker Lockout, Black

The Zing Green ZIN7316 Miniature Circuit Breaker Lockout is a two-way lockout device designed to secure toggle-style circuit breakers during maintenance. It attaches to the slot behind the switch toggle to prevent reenergization, providing a simple, code-compliant way to isolate a circuit for lockout/tagout procedures. The lockout is described as fitting larger two- or three-pole switches, with a two-inch by two-inch footprint and the ability to accommodate up to three padlocks, depending on the specific configuration and padlock shackle size.

Construction details indicate a toggle-slot engagement mechanism, with a design that includes detachable cleats and thumbscrew fastening to secure the device to the switch. The product is available in a three-size family intended to cover 120/277 V and 480/600 V applications, with the largest size designed to work on switches up to approximately 2-1/4 inches wide by 7/8 inch thick. Each unit accepts one padlock per cleat, enabling multiple users to lock out a single circuit as required by site procedures.

Suitable use cases include any facility maintenance scenario requiring lockout of electrical distribution equipment controlled by toggle switches. When selecting a lockout, verify the switch dimensions to ensure a proper fit with the larger size accommodating wider, thicker toggles. For best results, confirm the number of padlocks your team needs to secure and ensure the shackle diameter aligns with the lockout cleats. This product is sold as an individual lockout device; packaging and compatibility specifics should be checked if you’re stocking multiple lockout configurations for a given panel lineup.

Features:

• Three sizes cover 120/277V & 480/600V
• Large fits up to 2-1/4" W x 7/8" thick switches
• Thumbscrew fastening; detachable cleats (2)
• Each lockout accepts 1 padlock (0.35" shackle)
• Compact design for miniature circuit breakers
• Secure energy isolation during maintenance
