Vestil DBA-130 Semi-Automatic Probe Strapping Machine

The Vestil DBA-130 Semi-Automatic Pallet Probe Strapping Machine is designed to streamline pallet strapping by automatically feeding, tightening, and sealing polypropylene strap around a pallet. In a single cycle, the operator unfolds the pallet probe, inserts it into the pallet, feeds the strap, adjusts tension, and completes the heat seal before the strap is cut and fed out for the next pallet. This capability helps reduce manual handling and speeds up repetitive strapping tasks on standard pallets.

Constructed for practical, in-line operation, the unit features a steel frame finished in white for corrosion resistance and durability in typical industrial environments. The machine operates from a 115 V single-phase supply and supports polypropylene strap in 3/8, 1/2, and 5/8 inch widths. Key mechanical details include a maximum tension of 175 lb, an adjustable feed strip height of 53-1/2 inches, a foldable pallet probe at 40 inches, and 3-inch diameter casters with a 1-3/8 inch width for mobility. The design integrates automatic feed, tension adjustment, sealing, cutting, and discharge into one cycle, enabling rapid transitions from one pallet to the next without removing the equipment between loads.

Potential users should consider floor space availability given the machine’s footprint and ensure access to standard 115 V electrical supply. The DBA-130 is listed as a package-sized unit in the per-item configuration and is intended for use with standard pallet setups requiring probe-based strapping. For maintenance, routine inspection of the strap path and seal area is advised to sustain consistent cycle timing and fastening quality across multiple pallets.

Features:

• Speeds up pallet strapping operations
• Automatically straps, tightens, and seals around the pallet
• Single-cycle tension, cut-off, and feed control
• Simple transition between pallets without complex setup
• Solid steel construction for durability
