ILP’s VS8-7L/8L/9L-U-CCTS-FRL-FIOS is a Slim LED strip light fixture designed for versatile architectural applications. The unit comes in 4 ft and 8 ft lengths and features a steel housing with a white powder-coated finish, mounted with a round frosted acrylic lens. It is available in selectable color temperatures of 3500K, 4000K, and 5000K and delivers selectable wattages of 56, 61, or 66 watts, enabling a corresponding range of lumens that supports a broad set of spaces from corridors to warehouses and manufacturing areas. The fixture is 120–277V universal voltage and is dimmable via a 0–10V driver (full range 100% to 10%), allowing precise control of light levels in occupied and unoccupied scenarios. It is rated for wet and damp locations, enhancing its suitability for indoor spaces with occasional exposure to moisture or humidity, and is UL, ETL, and DLC listed (including DLC Premium), which signals compliance with recognized industry performance and efficiency standards. The design supports ceiling, wall, or suspension mounting and includes a junction box cover for straightforward installation.
With a robust steel construction and a slim profile, this strip light provides wide-area illumination with good color rendering (CRI ≥ 80) and economical power use, delivering an L70 lifetime in excess of 100,000 hours. The fixture is designed for modern facilities such as retail, warehouses, schools, hallways, distribution centers, and manufacturing environments where long life and reliable performance are critical. Installation considerations should include ensuring compatible mounting and driver dimming setups, and confirming that supplied color temperature and lumen output align with project requirements. Each package contains one unit, and it is covered by a 5-year warranty for added assurance.
Features:
- Selectable wattage: 56/61/66W
- Selectable color temperatures: 3500K, 4000K, 5000K
- 120-277V input; 135 lm/W; L70 >100,000 hours
- UL Listed, ETL Listed, DLC and DLC Premium Listed
- Dimmable via 0-10V
- Wet Location and Damp Location suitable
- 5-year warranty
- 8' slim strip, suspended mounting; steel housing with acrylic lens
- Package Size:
- Each
- Package Includes:
- 1/Each
- Wattage:
- 56/61/66 Selectable
- Lumens:
- 7946/8456/8951 Selectable
- Lumens Per Watt:
- 135
- Input Voltage:
- 120-277V
- Color Temp:
- 3500K, 4000K, 5000K Selectable
- CRI:
- >80
- Dimmable:
- 0-10V Dimmable
- UL Listed:
- Yes
- ETL Listed:
- Yes
- DLC Listed:
- Yes
- DLC Premium Listed:
- Yes
- Wet Location:
- Yes
- Damp Location:
- Yes
- Hazardous Location:
- No
- Certifications:
- ETL
- Housing Material:
- Steel
- Color Finish:
- White
- Lens Type:
- Acrylic
- Mounting Type:
- Suspended
- Shape:
- Strip
- Motion Sensor Included:
- No
- Emergency Battery Included:
- No
- Operating Temperature Range:
- -4°F - 122°F
- Life Rating L70:
- >100,000 Hours
- Warranty:
- 5 Years
